Product Details
Recirculated water is a crucial component in industrial systems, involving processes such as system cooling and boiler water supply. Industrial water sources typically include river, seawater, and groundwater, but the system water quality requirements are stringent. To better provide high-quality water for the system, advanced water treatment equipment is required, such as a removable-core industrial water filter that can better adapt to various operating conditions. This type of equipment is widely used in power plants, chemical industries, and other sectors, where preliminary filtration of industrial water is indispensable. The market prospects are vast, and our company's research on this type of equipment can better meet market demands. This equipment can also better replace outdated filtration systems, maximizing market economic benefits.
1. Features include:
(1) This filter model features a replaceable core with flexibility.
(2) Filter components are tightly matched on both sides, with no fitting gaps and no occurrence of heavy fitting gaps with impurities escaping.
(3) The effluent discharge unit is flexible, utilizing a flat funnel design for effluent discharge. The connection method features rolling operation without sliding friction, ensuring smooth operation and noiseless performance.
(4) Actuator consumes less power, operation is simple.
(5) The equipment has low water resistance during operation, reducing the resistance loss during water circulation.
(6) This model's filter components feature a stainless steel spherical cup structure, which increases the filtering area, enhances filtering accuracy, and offers a compact design.
2. Operating Principle:
The inlet flange connects to the incoming water pipe, where the circulating water enters the lower cylinder of the filter. The water passes through the filter core, with impurities trapped on the inside of the filter mesh. The purified water then rises to the upper part of the filter and flows out through the upper outlet into the system. When the pressure transmitter detects a high pressure difference across the filter core, the motor starts, rotating the reducer shaft to operate. The drain funnel rotates to below the filter mesh, and the external drain valve opens under water pressure for draining. The rotation axis rotates to the next filter core for draining every 2 minutes until the pressure difference is within the set range. If the filter mesh is damaged after long-term operation or when changing the filtration precision, the equipment manhole can be opened for replacement.
3. Selection Description:
