Recirculating water is a crucial component in industrial systems, involving system cooling and boiler water supply, among others. Industrial water sources typically include river, sea, and groundwater, but the water quality requirements for the system are high. To better provide high-quality water for the system, it requires advanced water treatment equipment. A removable-core industrial water filter can better adapt to various operational conditions. This type of equipment is widely used in power plants, chemical industries, and others, where preliminary filtration of industrial water is indispensable. The market prospects are vast, and our company's research on this type of equipment can better meet market demands. This equipment can also better replace outdated filtration systems, achieving economic benefits in the market.
1. Features include:
(1) This filter model features a replaceable core with flexibility.
(2) Filter components feature a tight fit on both sides, with no clearance gap and no occurrence of impurities escaping through significant gaps.
(3) The effluent unit is flexible, using a flat funnel design for effluent discharge. The connection method employs a rolling operation without sliding friction, ensuring smooth operation and noise-free performance.
(4) The actuator consumes less energy and is easy to operate.
(5) The equipment has low water resistance during operation, reducing the resistance loss during water circulation.
(6) The equipment filter features a stainless steel spherical cup structure, which increases the filtering area and enhances the filtration accuracy, while maintaining a compact design.
2. Operating Principle:
The inlet flange connects to the incoming water pipe, where the circulating water enters the lower cylinder of the filter. The water passes through the filter core, with impurities trapped on the inside of the filter mesh. The purified water then flows into the upper part of the filter and exits through the upper outlet, into the system. When the pressure transmitter detects an excessive pressure difference on both sides of the filter core, the motor starts, rotating the reducer shaft to operate. The drain funnel rotates to below the filter mesh, and the external drain valve opens, allowing drainage under water pressure. After 2 minutes of drainage, the rotation axis moves to the next filter core for drainage, continuing until the pressure difference is within the set range. If the filter mesh is damaged after long-term operation or when changing the filtration accuracy, the equipment manhole can be opened for replacement.
3. Selection Description:
