Clean various heat exchangers, condensers, industrial pipelines, boilers, and steam power plant condensers. GlanChem Co., Ltd. offers guaranteed cooperation.

Jining Green Chemical Technology Co., Ltd. (简称 Jining Green Cleaning Co.) was established in 2010 and is a professional company specializing in the cleaning of various industrial heat exchange equipment. The company has comprehensive business philosophy and the capability to develop industrial equipment cleaning technologies. We undertake cleaning services for industrial, private enterprises, chemical equipment, power station equipment, condensers, boilers, and boiler air preheaters; as well as air conditioning and heat exchange equipment cleaning. We also handle the cleaning and descaling of refrigeration and heating equipment.

Jining Green Clean Company stocks dozens of cleaning machines in various models ranging from 10mpa to 250mpa, as well as over a dozen chemical cleaning pump stations. Our primary services include power plants, chemical factories, oil refineries, food processing plants, corporate entities, and heating equipment. The company also provides long-term industrial heat exchanger cleaning and design solutions for industry clients.

Our company has newly acquired domestic cleaning machines and imported cleaning equipment. We have hired experienced technical specialists in the cleaning industry to achieve standardized and standardized cleaning of heat exchange equipment.

Chemical Cleaning Scale Removal Process

Recirculating Closed Loop Cleaning

Recirculation cleaning involves using two existing parallel deslagging pipelines to form a loop, creating a circulating system with the cleaning pump station. A certain concentration of acidic solution is added, which circulates within the sludge water pipes for cleaning. As the acid cleaning reaches a certain level, the acidic solution is continuously replenished. For short-distance single sludge water pipelines, if conditions permit, a temporary pipeline can be laid to form a recirculation loop for cleaning. This process must be carried out while the system is shut down, and it is complex and costly.

Breakbulk Cleaning

No two grey pipes should form a loop during cleaning; only a single grey pipe should be used for open circuit cleaning. The method involves connecting one end of the grey pipe to the cleaning unit and continuously preparing a specific concentration of cleaning solution in the mixing tank, then injecting it into the grey pipe continuously or intermittently. This process requires the addition of cleaning equipment during shutdown, which increases costs.

Continuous cleaning without downtime

The process involves continuously injecting a certain amount of acidic solution while operating under normal ash transportation conditions in the ash pipe, simultaneously introducing a specific quantity of ash pipe cleaning inhibitor and pipeline cleaning descaler. The system is flushed in an open-loop manner. The primary function of the cleaning additives is to promote the reaction between the acidic solution and ash deposits at a certain concentration and flow rate, while also increasing solubility in water, reducing airlock occurrences, and ensuring the quality of ash pipe cleaning.

The procedure is as follows: Before cleaning, first estimate the required acid amount based on the total scale in the pipeline. Then, calculate the acid addition rate and the flow rate of the ash slurry pipeline for the addition of corrosion inhibitors and pipeline cleaner by considering the ash water flow rate and acidity. During cleaning, take a sample at the front of the ash pipeline every 30 minutes to test the acidity and strictly control it by adjusting the acid flow rate. In the later stage of cleaning, take a sample at the end of the ash pipeline every 15 minutes to test the pH value. When the pH value reaches a certain level and remains unchanged for 30 minutes, the cleaning can be deemed complete.


2. High-pressure water jet cleaning machinery
High-pressure water jetting for cleaning offers high efficiency, low cost, non-damaging to workpieces, non-polluting to the environment, ease of operation, and safety advantages.
High-pressure water technology boasts the following advantages.

(1) Excellent Cleaning Quality - The high-pressure water jet cleaning of pipe and heat exchanger bores can thoroughly remove scale and obstructions from inside the pipes, revealing the metal surface. With its immense energy and ultra-sonic speed, the high-pressure water jet is fully capable of destroying hard scale and obstructions without causing any damage to the metal.

Since the pressure of high-pressure water is less than the compressive strength grade of metal, high-pressure cleaning will not damage the base being cleaned.

(2) Fast Cleaning Speed: Due to the combined action of water jet washing, splitting, shearing, and grinding, scaling can be quickly broken and removed, which is several to ten times faster than traditional chemical methods, sandblasting, shot peening, simple mechanical, and manual cleaning methods.

Additionally, components cleaned with high-pressure water jetting do not require secondary cleaning; however, after chemical cleaning, the surface chemical must be rinsed off with clear water.

(3) No Environmental Pollution: As high-pressure water jet cleaning uses pure water as the medium, it does not produce a large amount of dust like sandblasting, shot blasting, or simple mechanical cleaning, which can pollute the air and harm health. Nor does it generate a large volume of waste liquid like some chemical cleaning methods, which can contaminate rivers, soil, and water quality. The water jet cleaning with pure water as the medium is odorless, tasteless, and non-toxic. After atomization, the emitted jet can also reduce the dust concentration in the work area, lowering atmospheric dust from 80mg/m³ with other methods to below the national safety standards. Therefore, it does not cause any pollution.

3. Pipe Scale

(1) Classified by chemical composition, they can be categorized into carbonate scale, sulfate scale, silicate scale, and mixed scale, etc. The main components of carbonate scale are calcium carbonate and magnesium carbonate; the main components of sulfate scale and silicate scale are calcium sulfate and silicate compounds, respectively.

(2) Classified by physical properties, there are two types: scale that firmly adheres to the pot shell and pipe walls, and sediment that is loose and easy to detach.
Lime scale primarily forms due to the salts, such as calcium and magnesium, present in the boiler feedwater, which precipitate and adhere to the metal surface upon heating. Lime scale has a very low thermal conductivity, approximately 2-5 times less than that of ordinary steel. When lime scale accumulates on the boiler's heating surface, it significantly deteriorates heat transfer efficiency, affects the boiler's performance; it can easily lead to metal material damage due to localized overheating, even causing pipe explosion accidents; it also accelerates galvanic corrosion, leading to pipeline lime scale corrosion and speeding up the deterioration of the heating surface. Once lime scale forms, it should be promptly removed using mechanical or chemical methods.

Heat Exchanger and Refrigeration Equipment Cleaning - Choose GreenChem for Assurance
