Clean various heat exchangers, condensers, industrial pipelines, boilers, and steam power plant condensers. Glan Chemical Co., Ltd. offers guaranteed cooperation.

Jining Green Chemical Technology Co., Ltd. (简称 Jining Green Cleaning Co.) was established in 2010 and specializes in the cleaning of various industrial heat exchange equipment. The company boasts comprehensive business philosophy and the capability to research and develop industrial cleaning technologies. We undertake cleaning services for industrial, private enterprise, and corporate chemical equipment, power station equipment, power plant condensers, boilers, and boiler air preheaters; as well as air conditioning cleaning, heat exchange equipment cleaning, and cleaning of machinery and chemical equipment. We also handle cleaning of refrigeration and heating equipment for scale removal.

Jining Grean Cleaning Company stocks dozens of cleaning machines in various models ranging from 10mpa to 250mpa, as well as over a dozen chemical cleaning pump stations. We primarily serve enterprises such as power plants, chemical factories, oil mills, food factories, institutions, and heating equipment, and we also provide long-term industrial heat exchanger cleaning and solution design services to industry clients.

Our company has newly acquired domestic cleaning machines and imported cleaning equipment. We have hired experienced technical specialists in the cleaning industry to achieve standardization and regularization of heat exchange equipment cleaning.

Chemical Cleaning Scale Removal Process

Recirculating Closed Loop Cleaning

Recirculation cleaning utilizes two original parallel ash piping lines to form a loop, creating a circulating system with the cleaning pump station. It involves adding a certain concentration of acidic solution, allowing it to circulate and clean within the ash water pipes. As the acid washing process reduces the acidity, the solution is continuously replenished. For short-distance single ash water pipes, if conditions permit, a temporary pipeline can be laid to form a recirculating loop for cleaning. This process must be carried out while the system is shut down, and it is complex and costly.

Open path cleaning

No two grey pipes should form a loop during cleaning; only a single grey pipe should be used for open-loop cleaning. The method involves connecting one end of the grey pipe to the cleaning unit and continuously preparing a certain concentration of cleaning solution in the dosing tank, which is then injected into the grey pipe continuously or intermittently. This process requires additional cleaning equipment to be installed during shutdown, resulting in higher costs.

Continuous cleaning without shutdown

The process involves continuously injecting a specific amount of acidic solution while simultaneously introducing a certain quantity of ash conveying tube cleaning inhibitor and pipeline descaling agent, performing an open circuit cleaning. The main function of the cleaning aid is to promote the reaction between the acidic solution and the ash scale at a certain concentration and flow rate, while also increasing its solubility in water, reducing the occurrence of airlock, and ensuring the quality of ash pipe cleaning.

The procedure is as follows: Before cleaning, first estimate the required acid amount based on the total scale in the pipeline. Then, calculate the acid addition rate and the flow rate of the descaling agent and pipeline cleaning agent by considering the sludge water flow rate and acidity. During cleaning, take a sample at the front end of the sludge pipe every 30 minutes to test the acidity and strictly control it by adjusting the acid flow rate. In the later stage of cleaning, take a sample at the end of the sludge pipe every 15 minutes to test the pH value. When the pH value reaches a certain level and remains unchanged for 30 minutes, the cleaning can be deemed complete.


2. High-pressure water jet cleaning equipment
High-pressure water jet cleaning offers advantages such as high efficiency, low cost, non-damaging to workpieces, environmental protection, ease of operation, and safety.
The advantages of high-pressure water technology include:

(1) Excellent Cleaning Quality: The high-pressure water jet cleaning of pipeline and heat exchanger bores can completely remove scale and blockages inside, revealing the metal substrate. With immense energy and moving at supersonic speeds, the high-pressure water jet is fully capable of destroying tough scale and blockages without causing any damage to the metal.

High-pressure water cleaning will not damage the base material being cleaned, as the pressure is less than the compressive strength grade of the metal.

(2) Fast Cleaning Speed: Due to the combined action of water jet washing, wedge splitting, shearing, and grinding, scale can be quickly broken and removed, making the cleaning speed several to ten times faster than traditional chemical methods, sandblasting and shot peening techniques, simple mechanical, and manual methods.

Additionally, parts cleaned with high-pressure water jetting do not require a secondary cleaning process; however, after chemical cleaning, the surface chemical must be rinsed off with clean water.

(3) No Environmental Pollution - Since high-pressure water jet cleaning uses pure water as the medium, it does not generate a large amount of dust like sandblasting or simple mechanical cleaning, which can pollute the atmosphere and harm health. It also does not produce a significant amount of waste liquid like some chemical cleaning methods, which can contaminate rivers, soil, and water quality. The water jet, using pure water as the medium, is odorless, tasteless, and non-toxic. After atomization, the emitted jet can also reduce the dust concentration in the work area, lowering atmospheric dust levels from 80mg/m³ using other methods to below the national safety standards, thus causing no pollution.

Pipe Scale

(1) Classified by chemical composition, they can be categorized into carbonate scale, sulfate scale, silicate scale, and mixed scale, among others. The main components of carbonate scale are calcium carbonate and magnesium carbonate; the main components of sulfate scale and silicate scale are calcium sulfate and silicate compounds, respectively.

(2) Categorized by physical properties, there are two types: scale that firmly adheres to the pot shell and tube walls, and sediment that is loosely textured and easily detached.
Lime scale primarily forms due to the salts like calcium and magnesium in the boiler feed water, which precipitate and adhere to the metal surface upon heating. Lime scale has a very low thermal conductivity, approximately 2 to 5 times that of ordinary steel. When lime scale accumulates on the boiler's heating surface, it significantly worsens the heat transfer efficiency and affects the boiler's performance; it can easily cause metal materials to burn due to localized overheating, potentially leading to pipe explosion accidents; it also accelerates galvanic corrosion, causing pipeline lime scale corrosion and speeding up the damage to the heating surface. Once lime scale forms, it should be promptly removed using mechanical or chemical methods.

Heat Exchanger and Refrigeration Equipment Cleaning - Choose GreenChem for Confidence
