Clean various heat exchangers, condensers, industrial pipelines, boilers, and steam power plant condensers. Glan Chemical Co., Ltd. offers guaranteed cooperation.

Jining Green Chemical Technology Co., Ltd. (abbreviated as Jining Green Cleaning Co.) was established in 2010 and is a professional company specializing in the cleaning of various industrial heat exchange equipment. The company has comprehensive business philosophy and the capability to develop industrial cleaning technologies, undertaking cleaning services for industrial, private enterprise, corporate chemical equipment, power plant equipment, condensers, boilers, and economizers. We also provide air conditioning and heat exchange equipment cleaning, as well as cleaning for machinery and chemical equipment. We also take on the cleaning and descaling of refrigeration and heating equipment.
Heat Exchanger Cleaning in Lanshan, Yuyao, Shandong

Jining Greentech Cleaning Co. offers dozens of cleaning machines ranging from 10MPa to 250MPa, as well as over a dozen chemical cleaning pump stations. Our main services are provided to power plants, chemical factories, oil refineries, food processing plants, corporate entities, heating equipment, and more. The company also provides long-term industrial heat exchanger cleaning and solution design services to industry clients.

Our company has newly acquired domestic cleaning machines and imported cleaning equipment. We have hired experienced technical specialists in the cleaning industry to achieve standardization and regularization in heat exchanger cleaning.

Chemical cleaning and scaling removal process:

Recirculating closed-loop cleaning

Recirculating cleaning utilizes two original parallel ash pipelines to form a loop, creating a circulation system with the cleaning pump station. A certain concentration of acidic solution is added, allowing for recirculating cleaning within the ash water pipes. As the acid washing decreases to a certain level, the acidic solution is continuously replenished. For short-distance single ash water pipelines, if conditions permit, a temporary pipeline can be laid to form a recirculating loop for cleaning. This process must be carried out during shutdown, is complex, and has a higher cost.

Open Channel Cleaning

No two gray pipes can form a loop during cleaning; only a single gray pipe can be used for open-loop cleaning. The method involves connecting one end of the gray pipe to the cleaning unit, continuously preparing a certain concentration of cleaning solution in the mixing tank, and then injecting it into the gray pipe continuously or intermittently. This process requires additional cleaning equipment during shutdown, resulting in higher costs.

Continuous Operation Cleaning

The process involves continuously injecting a certain amount of acidic solution while the ash pipe is operating normally without interruption, simultaneously adding a specific quantity of ash-pipe running cleaning inhibitor and pipeline descaling agent. This is an open-circuit cleaning method. The primary function of the cleaning aids is to promote the reaction between the acidic solution and ash deposits at a certain concentration and flow rate, while also increasing solubility in water and reducing the formation of air blockages, ensuring the quality of ash-pipe cleaning.

The procedure is as follows: Before cleaning, estimate the required acid quantity based on the total scale in the pipeline. Then, calculate the acid addition rate and the flow rate of the sludge pipeline by considering the flux of gray water and acidity. During the cleaning process, collect a sample at the front end of the gray pipe every 30 minutes to test the acidity and strictly control it by adjusting the acid flow rate. In the later stage of cleaning, test the pH value at the end of the gray pipe every 15 minutes. When the pH value reaches a certain level and remains unchanged for 30 minutes, the cleaning can be deemed complete.
Heat Exchanger Cleaning in Lanshan, Y日照

2. High-pressure water jet cleaning equipment
High-pressure water jet cleaning offers advantages such as high efficiency, low cost, non-damaging to workpieces, non-polluting the environment, easy operation, and safety.
Advantages of high-pressure water technology include:

(1) Excellent Cleaning Quality - The high-pressure water jet cleaning for pipes and heat exchanger bores can thoroughly remove all scaling and blockages inside, revealing the metal substrate. With its immense energy and ultra-sonic speed, the high-pressure water jet is fully capable of destroying hard scaling and blockages, yet it has no destructive effect on metal.

The high-pressure water pressure is less than the compressive strength grade of metal, so high-pressure cleaning will not damage the substrate being cleaned.
Heat Exchanger Cleaning - Shandong Rizhao Lanshan

(2) Fast Cleaning Speed - Due to the combined actions of jet washing, splitting, shearing, and abrasive cutting, scale can be quickly broken and removed. This process is several to over a dozen times faster than traditional chemical methods, sandblasting, simple mechanical, and manual cleaning techniques.

Components cleaned with high-pressure water jetting do not require secondary cleaning; however, after chemical cleaning, the surface must be rinsed with clean water.
Heat Exchanger Cleaning - Lanshan, Yanzhou, Shandong

(3) No Environmental Pollution: Since high-pressure water jet cleaning uses pure water as the medium, it does not produce a large amount of dust like sandblasting, shot blasting, or simple mechanical cleaning, which can pollute the atmosphere and harm health. It also does not generate a significant amount of waste liquid like some chemical cleaning methods, which can contaminate rivers, soil, and water quality. The water jet cleaning with pure water as the medium is odorless, tasteless, and non-toxic. After atomization, it can also reduce the dust concentration in the work area, lowering atmospheric dust from 80mg/m³ using other methods to below the national safety standards, thus causing no pollution.

Heat Exchanger Cleaning - Shandong Rizhao Lanshan

3. Scale in Pipes

(1) Classified by chemical composition, they can be categorized into carbonate scale, sulfate scale, silicate scale, and mixed scale, etc. The main components of carbonate scale are calcium carbonate and magnesium carbonate; the main components of sulfate scale and silicate scale are calcium sulfate and silicate compounds, respectively.
Heat Exchanger Cleaning - Shandong, Rizhao Lanshan

(2) Classified by physical properties, there are two types: scale that is firmly adhered to the pot shell and tube walls, and sediment that is loosely textured and easily detached.
Lime scale primarily forms due to the salts of calcium and magnesium in the boiler feed water precipitating and adhering to the metal surface upon heating. The thermal conductivity of lime scale is very low, approximately 2 to 5 times that of ordinary steel. Lime scale deposited on the boiler's heating surface significantly worsens the heat transfer efficiency, impacting the boiler's performance; it can easily cause metal materials to burn due to local overheating, potentially leading to pipe explosion accidents; it also accelerates galvanic corrosion, causing pipeline lime scale corrosion, and speeding up the deterioration of the heating surface. Once lime scale forms, it should be promptly removed using either mechanical or chemical methods.

Heat Exchanger and Refrigeration Equipment Cleaning - Choose GreenChem for Confidence
