Clean various heat exchangers, condensers, industrial pipelines, boilers, and steam power plant condensers. Glan Chemical Co., Ltd. offers guaranteed cooperation.

Jining Greentech Chemical Technology Co., Ltd. (abbreviated as Jining Greentech Cleaning Co.) was established in 2010 and specializes in cleaning various industrial heat exchange equipment. The company has comprehensive business philosophy and the capability to research and develop industrial cleaning technologies. We undertake cleaning services for industrial, private enterprise, corporate chemical equipment, power plant equipment, condensers, boilers, and economizers. We also provide air conditioning cleaning, heat exchange equipment cleaning, and accept cleaning services for machinery and chemical equipment. Moreover, we handle cleaning and descaling of refrigeration and heating equipment.

Jining Grean Cleaning Co. has dozens of cleaning machines with various models ranging from 10mpa to 250mpa, as well as over a dozen chemical cleaning pump stations. Our main services are provided to power plants, chemical factories, oil refineries, food processing plants, corporate entities, heating equipment, and more. The company also offers long-term industrial heat exchanger cleaning and design solutions to industry clients.

Our company has newly acquired domestic cleaning machines and imported cleaning equipment. We have hired experienced technical specialists in the cleaning industry to standardize and normalize the cleaning process for heat exchange equipment.

Chemical cleaning descaling process:

Recirculating closed-loop cleaning

Recirculating cleaning utilizes two original parallel ash pipelines to form a loop, creating a recirculation system with the cleaning pump station. A solution of a certain concentration of acidity is added, which circulates within the ash water pipeline for cleaning. Additionally, as the acid washing decreases to a certain level, acid is continuously replenished. For short-distance single ash water pipelines, if conditions permit, a temporary pipeline can be laid to form a recirculation loop for cleaning. This process must be carried out during shutdown, and it is complex and costly.

Open Channel Cleaning

No two gray pipes can form a loop during cleaning; only a single gray pipe can be used for open-circuit cleaning. The method involves connecting one end of the gray pipe to the cleaning unit, continuously preparing a certain concentration of cleaning solution in the dosing tank, and then continuously or intermittently injecting it into the gray pipe. This process requires additional cleaning equipment during shutdown, which increases costs.

Continuous operation cleaning

The process involves continuously injecting a certain amount of acidic solution while the ash pipe is operating normally and not stopped, simultaneously adding a specific quantity of ash pipe operation cleaning inhibitor and pipeline cleaning descaler for open-loop cleaning. The primary function of the cleaning aid is to promote the reaction between the acidic solution and the ash scale at a certain concentration and flow rate, while also increasing its solubility in water and reducing the formation of air blockages, ensuring the quality of ash pipe cleaning.

Operation method: Prior to cleaning, estimate the required acid quantity based on the total scale in the pipeline. Then, calculate the acid addition rate and the flow rate for the injection of the cleaning inhibitor and pipeline descaler based on the sludge flow rate and acidity. During cleaning, collect a sample at the front of the sludge pipe every 30 minutes to test acidity and strictly control it by adjusting the acid flow rate. In the later stage of cleaning, collect a sample at the end of the sludge pipe every 15 minutes to test the pH value. When the pH value reaches a certain level and remains unchanged for 30 minutes, the cleaning process can be deemed complete.


2. High-pressure water cleaning machinery
High-pressure water jet cleaning offers advantages such as high efficiency, low cost, non-damaging to workpieces, environmental friendliness, ease of operation, and safety.
Advantages of high-pressure water technology include:

(1) High-quality Cleaning - The high-pressure water jet cleaning for pipes and the inner holes of heat exchangers can thoroughly remove scale and obstructions from inside the pipes, revealing the metal surface. The high-pressure water jet, with its immense energy and supersonic speed, is capable of completely destroying hard scales and obstructions without causing any damage to the metal.

High-pressure water cleaning will not damage the base material being cleaned, as the pressure is less than the compressive strength grade of the metal.

(2) Fast Cleaning Speed: Due to the combined action of water jet erosion, splitting, shearing, and grinding, scaling can be quickly broken and removed, which is several to ten times faster than traditional chemical methods, sandblasting and shot peening techniques, simple mechanical, and manual cleaning methods.

Parts cleaned with high-pressure water jetting do not require secondary cleaning; however, after chemical cleaning, the surface must be rinsed with clean water.

(3) No Environmental Pollution: Since high-pressure water jet cleaning uses pure water as the medium, it does not generate a large amount of dust like sandblasting, shot blasting, or simple mechanical cleaning, which can pollute the atmosphere and harm health. It also does not produce a large amount of waste liquid like some chemical cleaning methods, which can contaminate rivers, soil, and water quality. The water jet cleaning with pure water as the medium is odorless, tasteless, and non-toxic. After atomization, it can also reduce the dust concentration in the work area, lowering atmospheric dust from 80mg/m³ with other methods to below the national safety standards, thus causing no pollution.

Pipe Scale

(1) Classified by chemical composition, they can be categorized into carbonate scale, sulfate scale, silicate scale, and mixed scale, among others. The main components of carbonate scale are calcium carbonate and magnesium carbonate; the main components of sulfate scale and silicate scale are calcium sulfate and silicate compounds, respectively; mixed scale is usually a mixture of the above three types.

(2) Categorized by physical properties, there are two types: water scale that firmly adheres to the pot shell and tube walls, and sediment that is loosely textured and easily detached.
Lime scale primarily forms due to the salts like calcium and magnesium in the boiler feed water, which precipitate and adhere to the metal surface upon heating. Lime scale has a very low thermal conductivity, approximately 2 to 5 times that of ordinary steel. The presence of lime scale on the boiler's heating surface significantly worsens the heat transfer efficiency, affecting the boiler's performance; it can easily cause metal materials to burn due to localized overheating, even leading to pipe explosion accidents; it also accelerates galvanic corrosion, causing pipeline lime scale corrosion and speeding up the damage to the heating surface. Once lime scale forms, it should be promptly removed using mechanical or chemical methods.

Heat Exchanger and Refrigeration Equipment Cleaning - Choose GreenChem for Confidence
