Clean various heat exchangers, condensers, industrial pipelines, boilers, and power station equipment condensers - GreenChem Cooperation Ensures Reliability

Jining Greentech Chemical Technology Co., Ltd. (简称 Jining Greentech Cleaning Co.) was established in 2010 and specializes in cleaning various industrial heat exchange equipment. The company boasts comprehensive business philosophy and the capability to develop industrial cleaning technologies. We undertake cleaning services for industrial, private enterprise, and corporate chemical equipment, power plant equipment, condensers, boilers, and air preheaters, as well as air conditioning units and heat exchangers. We also handle cleaning of machinery and chemical equipment, and provide descaling services for refrigeration and heating equipment.

Jining Greentech Cleaning Co. has dozens of cleaning machines with various models ranging from 10mpa to 250mpa, as well as over a dozen chemical cleaning pump stations. Our main services are provided to power plants, chemical factories, oil refineries, food processing plants, corporate entities, heating equipment, and more. The company also offers long-term industrial heat exchanger cleaning and design solutions to clients in the industry.

Our company has newly acquired domestic cleaning machines and imported cleaning equipment. We have hired experienced technical specialists in the cleaning industry to achieve standardized and standardized cleaning of heat exchange equipment.

Chemical Cleaning and Scaling Removal Process

Recirculating Closed Loop Cleaning

Recirculating cleaning utilizes two existing parallel ash removal pipelines to form a loop, creating a recirculation system with the cleaning pump station. A certain concentration of acidic solution is added, which circulates through the ash water pipes for cleaning. As the acid washing decreases to a certain level, the acidic solution is continuously replenished. For short-distance single ash water pipelines, if conditions permit, a temporary pipeline can be laid to form a recirculation loop for cleaning. This process must be carried out while the system is shut down, and it is complex and costly.

Pilot cleaning

No two ash pipes should form a loop during cleaning; only a single ash pipe should be used for open-circuit cleaning. The method involves connecting one end of the ash pipe to the cleaning unit, continuously preparing a certain concentration of cleaning solution in the mixing tank, and then injecting it into the ash pipe continuously or intermittently. This process requires the addition of cleaning equipment during shutdown, which increases costs.

Continuous operation cleaning

The process involves continuously injecting a certain amount of acidic solution while the ash pipeline operates normally, without halting the ash transportation. Simultaneously, a certain amount of ash pipeline cleaning inhibitor and pipeline cleaning descaler is injected for operation. The cleaning is conducted by opening the circuit. The primary function of the cleaning aids is to facilitate the reaction between the acidic solution and ash deposits at a certain concentration and flow rate, while also increasing the solubility in water, reducing the occurrence of airlock, and ensuring the quality of ash pipeline cleaning.

The procedure is as follows: Before cleaning, first estimate the required acid amount based on the total scale in the pipeline. Then, calculate the acid addition rate and the flow rate of the sludge pipe operation by considering the flow rate of the gray water and the acidity. During cleaning, take samples at the sampling point at the front of the gray pipe every 30 minutes to test the acidity, and strictly control the acidity by adjusting the flow rate of acid addition. In the later stage of cleaning, take samples at the end of the gray pipe every 15 minutes to test the pH value. When the pH value reaches a certain level and remains unchanged for 30 minutes, the cleaning can be deemed complete.

2. High-pressure water jet cleaning equipment
High-pressure water jet cleaning offers advantages such as high efficiency, low cost, non-damaging to workpieces, non-polluting the environment, easy operation, and safety.
High-pressure water technology boasts the following advantages.

(1) Excellent Cleaning Quality: The high-pressure water jet cleaning method for pipes and the internal holes of heat exchangers can remove all scale and obstructions from within the pipes, revealing the metal surface. The high-pressure water jet, with its immense energy and supersonic speed, is fully capable of breaking down hard scale and obstructions without causing any damage to the metal.

Due to the pressure of high-pressure water being less than the compressive strength grade of metal, high-pressure cleaning will not damage the base material being cleaned.

(2) Rapid Cleaning Speed: Due to the combined fracturing effects of water jet scouring, wedge splitting, shearing, and abrasive cutting, scale can be quickly broken and removed, making the cleaning process several to ten times faster than traditional chemical methods, sandblasting, ball-blasting, simple mechanical, and manual methods.

Parts cleaned with high-pressure water jetting do not require secondary cleaning; however, chemical cleaning requires rinsing the surface with clean water.

(3) No Environmental Pollution: As high-pressure water jet cleaning uses pure water as the medium, it does not produce a large amount of dust like sandblasting, shot blasting, or simple mechanical cleaning, which can pollute the air and harm health. It also does not generate large amounts of waste liquid like some chemical cleaning methods, which can contaminate rivers, soil, and water quality. The water jet cleaning with pure water is odorless, tasteless, and non-toxic. After atomization, the emitted jet can also reduce the dust concentration in the work area, lowering atmospheric dust from 80mg/m³ with other methods to below the national safety standards. Therefore, it does not cause any pollution.

3. Pipe Scale

(1) Classified by chemical composition, they can be categorized into carbonate scale, sulfate scale, silicate scale, and mixed scale, etc. The main components of carbonate scale are calcium carbonate and magnesium carbonate; the main components of sulfate scale and silicate scale are calcium sulfate and silicate compounds, respectively.

(2) Classified by physical properties, there are two types: scale that firmly adheres to the pot shell and pipe walls, and sediment that is loosely textured and easy to dislodge.
Lime scale primarily forms due to the salts of calcium and magnesium in the boiler feed water, which precipitate and adhere to the metal surface upon heating. Lime scale has a very low thermal conductivity, approximately 2 to 5 times that of ordinary steel. When lime scale accumulates on the boiler's heat exchange surface, it severely degrades the heat transfer efficiency and affects the boiler's performance; it can easily cause metal materials to burn due to localized overheating, potentially leading to burst pipe accidents; it also accelerates galvanic corrosion, causing pipeline lime scale corrosion and speeding up the damage to the heat exchange surface. Once lime scale forms, it should be promptly removed using either mechanical or chemical methods.

Heat Exchanger and Refrigeration Equipment Cleaning – Choose GreenChem for Confidence
