Clean various heat exchangers, condensers, industrial pipelines, boilers, and steam power plant condensers. Greentech Chemicals offers guaranteed cooperation.

Jining Greentech Chemical Technology Co., Ltd. (简称 Jining Greentech Cleaning Co.) was established in 2010 and specializes in the cleaning of various industrial heat exchange equipment. The company boasts comprehensive business philosophy and the capability to develop industrial equipment cleaning technology. We undertake cleaning services for industrial, private enterprise, corporate chemical equipment, power plant equipment, condensers, boilers, and economizers. Additionally, we provide air conditioning cleaning, heat exchange equipment cleaning, and cleaning services for machinery and chemical equipment. We also handle cleaning and descaling of refrigeration and heating equipment.

Condenser Cleaning Reputable Supplier in Shandong Rizhao Wulian

Jining Grean Cleaning Co. offers dozens of cleaning machines with various models ranging from 10mpa to 250mpa, as well as over a dozen chemical cleaning pump stations. Our primary services include power plants, chemical factories, oil refineries, food processing plants, corporate entities, heating equipment, and more. The company also provides long-term industrial heat exchanger cleaning and solution design services to industry clients.

Our company has newly acquired domestic cleaning machines and imported cleaning equipment. We have hired experienced technical experts in the cleaning industry, achieving standardized and standardized cleaning of heat exchange equipment.

Steam Condenser Cleaning - Reliable Contractor in Shandong, Rizhao, Wulian

Chemical cleaning descaling process:

Recirculating Closed Loop Cleaning

Recirculating cleaning utilizes two existing parallel ash pipelines to form a loop, creating a circulation system with the cleaning pump station. A certain concentration of acidic solution is added, which circulates through the ash water pipes for cleaning. As the acid washing reaches a certain level, the solution is continuously replenished with more acid. For short-distance single ash water pipelines, if conditions permit, a temporary pipeline can be laid to form a recirculation loop for cleaning. This process must be carried out while the system is shut down, and it is complex and costly.

Condenser Cleaning Reputable Supplier in Shandong Rizhao Wulian

Open road cleaning

No two gray pipes should form a loop during cleaning; only single-pipe open circuit cleaning is allowed. The method involves connecting one end of the gray pipe to the cleaning unit, continuously preparing a specific concentration of cleaning solution in the dosing tank, and then continuously or intermittently injecting it into the gray pipe. This process requires the addition of cleaning equipment during shutdown, which increases costs.

Condenser Cleaning Reputable Supplier in Shandong Rizhao Wulian

Continuous Operation Cleaning

The process involves continuously injecting a certain amount of acidic fluid into the ash pipeline while it is operating normally, without stopping the ash transportation. Simultaneously, a certain amount of ash-pipeline operating cleaner corrosion inhibitor and pipeline cleaner stripper is added for open-circuit cleaning. The primary function of the cleaning additive is to promote the reaction between the acidic fluid and the ash deposits within a specific concentration and flow rate, while also enhancing its solubility in water, reducing the formation of air blockages, and ensuring the quality of ash pipeline cleaning.

The procedure is as follows: Before cleaning, first estimate the required acid amount based on the total scale in the pipeline. Then, calculate the acid addition rate and the flow rate of the descaling agent and pipeline cleaner by considering the sludge flow rate and acidity. During cleaning, take a sample at the front end of the sludge pipe every 30 minutes to test the acidity and strictly control it by adjusting the acid flow rate. In the later stage of cleaning, take a sample at the end of the sludge pipe every 15 minutes to test the pH value. When the pH value reaches a certain level and remains unchanged for 30 minutes, the cleaning can be deemed complete.


2. High-pressure water jet cleaning equipment
High-pressure water jet cleaning offers advantages such as high efficiency, low cost, non-damaging to workpieces, environmental friendliness, ease of operation, and safety.
The advantages of high-pressure water technology are as follows.

(1) Excellent Cleaning Quality - High-pressure water jet cleaning of pipes and the internal holes of heat exchangers can thoroughly remove scale and blockages from within the pipes, revealing the metal surface. The high-pressure water jet, with its immense energy and ultra-sonic speed, is fully capable of destroying tough scale and blockages without causing any damage to the metal.

Since the pressure of high-pressure water is less than the pressure rating of metal, high-pressure cleaning will not damage the surface being cleaned.

(2) Fast Cleaning Speed: Due to the combined action of water jet washing, wedge splitting, shearing, and grinding, scale can be quickly broken and removed, which is several to ten times faster than traditional chemical methods, sandblasting and shot peening techniques, simple mechanical, and manual cleaning methods.

Additionally, parts cleaned with high-pressure water jetting do not require secondary cleaning; whereas, after chemical cleaning, the surface chemical agents must be rinsed off with clean water.

(3) No Environmental Pollution - Since high-pressure water jet cleaning uses pure water as the medium, it does not generate a large amount of dust like sandblasting, grit-blasting, or simple mechanical cleaning, which can pollute the atmosphere and harm health. It also does not produce a significant amount of waste liquid like some chemical cleaning methods, which can contaminate rivers, soil, and water quality. The water jet cleaning using pure water is odorless, tasteless, and non-toxic. After atomization, the emitted jet can also reduce the dust concentration in the work area, lowering atmospheric dust levels from 80mg/m³ using other methods to below the national safety standards, thus causing no pollution.

Condenser Cleaning Reliable Vendor - Shandong Rizhao Wulian

Pipe Scale

(1) Classified by chemical composition, they can be categorized into carbonate scale, sulfate scale, silicate scale, and mixed scale, etc. The main components of carbonate scale are calcium carbonate and magnesium carbonate; the main components of sulfate scale and silicate scale are calcium sulfate and silicate compounds, respectively; mixed scale is mostly a mixture of the above three types.

Steam Condenser Cleaning with Confidence - Powerful Supplier in Shandong, Rizhao, Wulian

(2) Categorized by physical properties, there are two types: scale that is firmly adhered to the pot shell and tube walls, and sediment that is loosely textured and easily detached.
Lime scale primarily forms due to the salts like calcium and magnesium in the boiler feed water, which precipitate and adhere to the metal surface upon heating. Lime scale has a very low thermal conductivity, approximately 2 to 5 times that of ordinary steel. When lime scale accumulates on the boiler's heating surface, it severely degrades heat transfer efficiency and affects the boiler's performance; it can also lead to the deterioration of metal materials due to localized overheating, potentially causing pipe explosion accidents; it accelerates galvanic corrosion, leading to pipeline lime scale corrosion and speeding up the damage to the heating surface. Once lime scale forms, it should be promptly removed using mechanical or chemical methods.

Heat Exchanger & Refrigeration Equipment Cleaning – Choose GreenChem for Confidence
