Clean various heat exchangers, condensers, industrial pipelines, boilers, and power plant equipment condensers. Glan Chemical Co., Ltd. offers guaranteed cooperation.

Jining Green Chemical Technology Co., Ltd. (简称 Jining Green Cleaning Co.) was established in 2010 and is a professional company specializing in the cleaning of various industrial heat exchange equipment. The company has comprehensive business philosophy and the capability to develop industrial equipment cleaning technologies, undertaking cleaning services for industrial, private enterprises, corporate chemical equipment, power plant equipment, condensers, boilers, and boiler air preheaters; as well as air conditioning and heat exchange equipment cleaning. We also handle cleaning of mechanical and chemical equipment, and descaling of refrigeration and heating equipment.

Jining Greentec Cleaning Co. boasts dozens of cleaning machines in various models ranging from 10MPa to 250MPa, as well as more than a dozen chemical cleaning pump stations. Our main services are provided to power plants, chemical factories, oil mills, food factories, enterprises and institutions, heating equipment, and more. The company also offers long-term industrial heat exchanger cleaning and solution design services to industry clients.

Our company has newly acquired domestic cleaning machines and imported cleaning equipment. We have hired experienced technical specialists in the cleaning industry to achieve standardized and regulated cleaning of heat exchange equipment.

Heating exchanger cleaning in Dongying, Shandong

Chemical cleaning descaling process:

Recirculating Closed Loop Cleaning

Recirculation cleaning utilizes two original parallel ash piping lines to form a loop, creating a circulating system with the cleaning pump station. A certain concentration of acidic solution is added, which circulates through the ash water pipes for cleaning. As the acid cleaning reaches a certain level, the acidic solution is continuously replenished. For short-distance single ash water pipes, if conditions permit, a temporary pipeline can be laid to form a recirculation loop for cleaning. This process must be carried out while the system is shut down and is complex, with higher costs.
Heating Exchanger Cleaning in Dongying, Shandong

Preliminary Cleaning

No two gray pipes can form a loop during cleaning; only single-pipe open circuit cleaning is allowed. The method involves connecting one end of the gray pipe to the cleaning unit and continuously preparing a specific concentration of cleaning solution in the mixing tank, which is then continuously or intermittently injected into the gray pipe. This process requires adding cleaning equipment during shutdown, which increases costs.

Continuous operation cleaning

The process involves continuously injecting a certain amount of acidic solution while the ash pipeline is operating normally without interruption, simultaneously adding a specific quantity of ash pipeline operation cleaning inhibitor and pipeline cleaning descaler for open-circuit cleaning. The primary function of the cleaning aids is to promote the reaction between the acidic solution and the ash scale at a certain concentration and flow rate, while also increasing its solubility in water and reducing the occurrence of air blockage, ensuring the quality of ash pipeline cleaning.

Operation method: Prior to cleaning, estimate the required acid quantity based on the total scale in the pipeline. Then, calculate the acid addition rate and the flow rate of the sludge pipeline by considering the gray water flow rate and acidity. During cleaning, take samples at the front end of the sludge pipeline every 30 minutes to test the acidity, and strictly control the acidity by adjusting the acid flow rate. In the later stages of cleaning, test the pH value at the end of the sludge pipeline every 15 minutes. When the pH value reaches a certain level and remains unchanged for 30 minutes, the cleaning process can be deemed complete.
Heating exchanger cleaning in Dongying, Shandong

2. High-pressure water jet cleaning equipment
High-pressure water jet cleaning offers advantages such as high efficiency, low cost, non-damaging to workpieces, non-polluting the environment, easy operation, and safety.
The high-pressure water technology boasts the following advantages.

(1) Excellent Cleaning Quality - The high-pressure water jet cleaning for pipes and heat exchanger bores can thoroughly remove all scaling and obstructions inside, revealing the metal substrate. With its immense energy and supersonic speed, the high-pressure water jet is fully capable of destroying hard scaling and obstructions without causing any damage to the metal.

The high-pressure water pressure is less than the tensile strength grade of metal, so high-pressure cleaning will not damage the substrate being cleaned.
Heating exchanger cleaning in Dongying, Shandong

(2) Fast Cleaning Speed: Due to the combined effects of jet washing, wedging, shearing, and abrasion, scale can be quickly broken and removed, which is several to ten times faster than traditional chemical methods, sandblasting, simple mechanical, and manual cleaning methods.

Components cleaned with high-pressure water jetting do not require secondary cleaning; however, after chemical cleaning, the surface must be washed with clean water.
Heating exchanger cleaning in Dongying, Shandong

(3) No Environmental Pollution: As high-pressure water jet cleaning uses pure water as the medium, it does not produce a large amount of dust like sandblasting, shot blasting, or simple mechanical cleaning, which can pollute the air and harm health. It also does not generate a large volume of waste liquid like some chemical cleaning methods, which can contaminate rivers, soil, and water quality. The water jet cleaning with pure water as the medium is odorless, tasteless, and non-toxic. After atomization, it can also reduce the dust concentration in the work area, lowering atmospheric dust levels from 80mg/m³ with other methods to below the national safety standards. Therefore, it does not cause any pollution.

3. Pipe Scale

(1) Classified by chemical composition, they can be categorized into carbonate scale, sulfate scale, silicate scale, and mixed scale, etc. The main components of carbonate scale are calcium carbonate and magnesium carbonate; the main components of sulfate scale and silicate scale are calcium sulfate and silicate compounds, respectively; mixed scale is usually a mixture of the above three types of scales.

(2) Categorized by physical properties, there are two types: a hard scale that firmly adheres to the pot shell and pipe walls, and a loose sediment that is easily detached.
Scale primarily forms due to the salts of calcium and magnesium present in the boiler feed water, which precipitate and adhere to the metal surface upon heating. The thermal conductivity of scale is very low, approximately 2 to 5 times that of ordinary steel. Scale buildup on the boiler's heating surface significantly worsens heat transfer efficiency, affecting the boiler's performance; it can easily lead to the burnout of metal materials due to localized overheating, even causing pipe explosion accidents; it also accelerates galvanic corrosion, leading to pipeline scale corrosion and hastening the damage to the heating surface. Once scale forms, it should be promptly removed using mechanical or chemical methods.

Heat Exchanger & Refrigeration Equipment Cleaning - Choose GreenChem for Confidence
