Clean various heat exchangers, condensers, industrial pipelines, boilers, and steam power plant condensers. GlanChem partnership is guaranteed.

Jining Green Chemical Technology Co., Ltd. (简称 Jining Green Cleaning Co.) was established in 2010 and is a professional company specializing in the cleaning of various industrial heat exchange equipment. The company possesses comprehensive business philosophy and the capability to develop industrial equipment cleaning technology, undertaking cleaning services for industrial, private enterprises, corporate chemical equipment, power station equipment, power plant condensers, boilers, and boiler air preheaters; as well as air conditioning and heat exchange equipment cleaning. We also handle cleaning of mechanical and chemical equipment, and descaling of refrigeration and heating equipment.

Jining Greentech Cleaning Co. offers dozens of cleaning machines in various models ranging from 10mpa to 250mpa, as well as over a dozen chemical cleaning pump stations. Our main services are provided to power plants, chemical factories, oil refineries, food processing plants, enterprises and institutions, heating equipment, etc. The company also provides long-term industrial heat exchanger cleaning and design services to industry clients.

Our company has newly acquired domestic cleaning machines and imported cleaning equipment. We've hired experienced technical specialists in the cleaning industry to standardize and regulate the cleaning of heat exchange equipment.

Chemical Cleaning Scale Removal Process

Recirculating Closed Circuit Cleaning

Recirculating cleaning utilizes two original parallel deslagging pipelines to form a circuit, which, combined with the cleaning pump station, creates a recirculation system. A solution of a certain acidity concentration is added, and the slurry flows through the pipeline in a recirculation process for cleaning. Acid washing is continuously replenished as the acidity level decreases. For short-distance single slurry pipelines, if conditions permit, a temporary pipeline can be installed to form a recirculation circuit for cleaning. This process must be carried out while the system is offline, and it is complex and expensive.

Open Road Cleaning

No two ash pipes should form a loop during cleaning; only a single ash pipe should be used for open circuit cleaning. The method involves connecting one end of the ash pipe to the cleaning unit, continuously preparing a specific concentration of cleaning solution in the mixing tank, and then injecting it into the ash pipe continuously or intermittently. This process requires additional cleaning equipment during shutdown, which increases costs.

Continuous Operation Cleaning

The process involves continuously injecting a certain amount of acidic fluid while the ash pipeline is operating normally without interruption. Simultaneously, a certain amount of ash-pipeline operation cleaning inhibitor and pipeline descaling agent are added for open-circuit cleaning. The main function of the cleaning aids is to promote the reaction between the acidic fluid and ash scale at a certain concentration and flow rate, while also increasing its solubility in water, reducing the formation of air blockages, and ensuring the quality of ash pipeline cleaning.

The procedure is as follows: Prior to cleaning, estimate the required acid quantity based on the total scale in the pipeline. Then, calculate the acid addition rate and the flow rate for the sludge pipe operation, incorporating the flow rate of the gray water and the acidity. During the cleaning process, take samples at the sampling point at the front end of the gray pipe every 30 minutes to test the acidity, and strictly control the acidity by adjusting the flow rate of acid addition. In the later stage of cleaning, take samples at the end of the gray pipe every 15 minutes to test the pH value. When the pH value reaches a certain level and remains unchanged for 30 minutes, the cleaning process can be deemed complete.

2. High-pressure water cleaning machinery
High-pressure water jetting for cleaning offers high efficiency, low costs, non-damaging to workpieces, environmental protection, ease of operation, and safety advantages.
The advantages of high-pressure water technology are as follows.

(1) Excellent Cleaning Quality: The high-pressure water jet cleaning of pipeline and heat exchanger bores can remove all scale and blockages from inside the pipes, revealing the metal itself. With immense energy and moving at supersonic speed, the high-pressure water jet is fully capable of destroying hard scale and blockages, yet it exerts no destructive effect on the metal.

Since the pressure of high-pressure water is less than the pressure resistance grade of metal, high-pressure cleaning will not damage the base material being cleaned.

(2) Fast Cleaning Speed: Due to the combined effects of water jet scouring, wedging, shearing, and grinding, scale can be quickly broken and removed, making the cleaning process several to ten times faster than traditional chemical methods, sandblasting, ball peening, simple mechanical, and manual methods.

Additionally, components cleaned with high-pressure water jetting do not require secondary cleaning; however, after chemical cleaning, the surface must be rinsed with clean water.

(3) No Environmental Pollution: Since high-pressure water jet cleaning uses pure water as the medium, it does not generate a large amount of dust like sandblasting, shot blasting, or simple mechanical cleaning, which can pollute the atmosphere and harm health. It also does not produce a large volume of waste liquid like some chemical cleaning methods, which can contaminate rivers, soil, and water quality. The water jet cleaning with pure water as the medium is odorless, tasteless, and non-toxic. After atomization, it can also reduce the dust concentration in the work area, lowering atmospheric dust from 80mg/m³ with other methods to below the national safety standards, thus causing no pollution.

3. Pipe Scale

(1) Classified by chemical composition, it can be divided into carbonate scale, sulfate scale, silicate scale, and mixed scale, etc. The main components of carbonate scale are calcium carbonate and magnesium carbonate; the main components of sulfate scale and silicate scale are calcium sulfate and silicate compounds, respectively.

(2) Classified by physical properties, there are two types: hard scale that firmly adheres to the pot shell and pipe walls, and loose sediment that is easy to detach.
Scale primarily forms due to the salts of calcium and magnesium in the boiler feedwater, which precipitate and adhere to the metal surface upon heating. The thermal conductivity of scale is very low, around 2 to 5 times that of ordinary steel. Scale buildup on the boiler's heat transfer surface significantly worsens heat transfer efficiency and affects the boiler's performance; it can easily lead to metal material damage due to localized overheating, even causing pipe explosion accidents; it also accelerates galvanic corrosion, leading to pipeline scale corrosion and hastening the deterioration of the heat transfer surface. Once scale forms, it should be promptly removed using mechanical or chemical methods.
