Clean various heat exchangers, condensers, industrial pipelines, boilers, and steam power plant condensers — Glan Chemical Co. offers reliable partnerships.

Jining Green Chemical Technology Co., Ltd. (abbreviated to Jining Green Cleaning Co.) was established in 2010 and specializes in cleaning various industrial heat exchange equipment. The company boasts comprehensive business philosophy and the capability to research and develop industrial cleaning technologies. We undertake cleaning services for industrial, private enterprise, and corporate chemical equipment, power plant equipment, condensers, boilers, and boiler air preheaters; as well as air conditioning and heat exchange equipment cleaning. We also handle cleaning and descaling of refrigeration and heating equipment.

Jining Green Cleaning Co. offers a wide range of cleaning machines from 10mpa to 250mpa, with dozens of units in stock and over a dozen chemical cleaning pump stations. Our primary services include power plants, chemical factories, oil refineries, food processing plants, corporate entities, heating equipment, and more. The company also provides long-term industrial heat exchanger cleaning and design services to industry clients.

Our company has newly acquired domestic cleaning machines and imported cleaning equipment. We have hired experienced technical specialists in the cleaning industry to achieve standardized and standardized cleaning of heat exchange equipment.

Chemical Cleaning Scale Removal Process

Recirculating Closed Loop Cleaning

Recirculating cleaning utilizes two existing parallel ash line pipes to form a loop, creating a recirculation system with the cleaning pump station. A solution of a certain acidity is added, which circulates within the ash water pipes for cleaning. As the acid washing process reaches a certain point, acid is continuously replenished. For short-distance single ash water pipelines, if conditions permit, a temporary pipeline can be installed to create a recirculation loop for cleaning. This process must be carried out while the system is offline and is complex, with higher costs.

Open Channel Cleaning

No two gray pipes can form a loop during cleaning; only a single gray pipe can be used for open-loop cleaning. The method involves connecting one end of the gray pipe to the cleaning unit, continuously preparing a certain concentration of cleaning solution in the mixing tank, and then continuously or intermittently injecting it into the gray pipe. This process requires adding cleaning equipment during shutdown, which increases costs.

Non-stop machine cleaning

The process involves continuously injecting a certain amount of acidic solution while operating the ash conveying pipes, simultaneously introducing a specific quantity of ash conveying pipe running cleaning inhibitor and pipeline descaling agent for open-loop cleaning. The primary function of the cleaning aids is to promote the reaction between the acidic solution and the ash deposits at a certain concentration and flow rate, while also increasing the solubility in water, reducing the occurrence of gas blockages, and ensuring the quality of ash pipe cleaning.

The procedure is as follows: First, estimate the required acid amount based on the total scale in the pipeline before cleaning. Then, calculate the acid addition rate and the flow rate of the sludge pipeline by considering the flow rate of the gray water and the acidity. During cleaning, take a sample at the front end of the gray pipe every 30 minutes to test the acidity and strictly control it by adjusting the flow rate of acid addition. In the later stage of cleaning, take a sample at the end of the gray pipe every 15 minutes to test the pH value. When the pH value reaches a certain level and remains unchanged for 30 minutes, the cleaning can be deemed complete.

2. High-pressure water jet cleaning machinery
High-pressure water jet cleaning offers advantages such as high efficiency, low cost, non-damaging to workpieces, environmental protection, ease of operation, and safety.
High-pressure water technology boasts the following advantages.

(1) Excellent Cleaning Quality: High-pressure water jet cleaning for pipes and the inner holes of heat exchangers can completely remove scale and blockages inside, revealing the metal surface. The high-pressure water jet, with its immense energy and supersonic speed, can fully destroy tough scale and blockages without causing any damage to the metal.

Due to the pressure of high-pressure water being less than the compressive strength grade of metal, high-pressure cleaning will not damage the base material being cleaned.

(2) Fast Cleaning Speed: Due to the combined action of water jet washing, wedging, shearing, and grinding, scaling can be quickly broken and removed, which is several to ten times faster than traditional chemical methods, sandblasting and shot peening techniques, simple mechanical, and manual cleaning methods.

Components cleaned with high-pressure water jetting do not require secondary cleaning; however, after chemical cleaning, the surface needs to be washed off with clear water.

(3) No Environmental Pollution - Since high-pressure water jet cleaning uses clean water as the medium, it does not produce a large amount of dust like sandblasting, grit blasting, or simple mechanical cleaning, which can pollute the air and harm health. It also does not generate a large volume of waste liquid like some chemical cleaning methods, which can contaminate rivers, soil, and water quality. The water jet, using clean water as the medium, is odorless, tasteless, and non-toxic. After atomization, the emitted jet can also reduce the dust concentration in the work area, lowering atmospheric dust from 80mg/m³ with other methods to below the national safety standards, thus causing no pollution.

Pipe Scale

(1) Classified by chemical composition, they can be categorized into carbonate scale, sulfate scale, silicate scale, and mixed scale, etc. The main components of carbonate scale are calcium carbonate and magnesium carbonate; the main components of sulfate scale and silicate scale are calcium sulfate and silicate compounds, respectively.

(2) Categorized by physical properties, there are two types: hard scale that firmly adheres to the pot shell and pipe walls, and loose sediment that is easy to detach.
Lime scale primarily forms due to the salts like calcium and magnesium in the boiler feed water, which precipitate and adhere to the metal surface upon heating. Lime scale has a very low thermal conductivity, approximately 2 to 5 times that of ordinary steel. When lime scale accumulates on the boiler's heating surface, it significantly worsens the heat transfer efficiency and affects the boiler's performance; it can easily cause metal materials to burn due to localized overheating, potentially leading to pipe explosion accidents; it also accelerates galvanic corrosion, causing pipeline lime scale corrosion and speeding up the damage to the heating surface. Once lime scale forms, it should be promptly removed using mechanical or chemical methods.

Heat Exchanger & Refrigeration Equipment Cleaning - Choose Green Chemical for Assurance
