Clean various heat exchangers, condensers, industrial pipelines, boilers, and steam power plant economizers. GlanChem partnership offers assurance.

Jining GreenChem Technology Co., Ltd. (Abbreviated as Jining GreenChem Cleaning Co.) was established in 2010 and specializes in the cleaning of various industrial heat exchange equipment. The company boasts comprehensive business philosophy and the capability to research and develop industrial cleaning technologies. We undertake cleaning services for industrial, private enterprise, and corporate chemical equipment, power plant equipment, condensers, boilers, and economizers. We also provide air conditioning and heat exchange equipment cleaning, as well as cleaning for mechanical and chemical equipment. In addition, we offer cleaning services for refrigeration and heating equipment to remove scale.

Chemical Equipment Cleaning in Junan, Linyi, Shandong

Jining Grean Cleaning Co. has dozens of cleaning machines ranging from 10mpa to 250mpa and over a dozen chemical cleaning pump stations. Our main services are provided to power plants, chemical factories, oil refineries, food processing plants, corporate entities, heating equipment, and more. The company also offers long-term industrial heat exchanger cleaning and design solutions to industry clients.

Our company has newly acquired domestic cleaning machines and imported cleaning equipment. We have hired experienced technical specialists in the cleaning industry to achieve standardized and standardized cleaning of heat exchange equipment.

Chemical Cleaning Scale Removal Process

Recirculating Closed-loop Cleaning

Recirculating cleaning utilizes two existing parallel deslagging pipelines to form a loop, creating a circulating system with the cleaning pump station. A solution of a certain concentration is added, and it circulates within the sludge water pipes for cleaning. As the acid washing reaches a certain level, the acid solution is continuously replenished. For short-distance single sludge water pipelines, if conditions permit, a temporary pipeline can be laid to form a recirculating loop for cleaning. This process must be carried out during shutdown and is complex and costly.
Chemical Equipment Cleaning in Jinnan, Linyi, Shandong

Open path cleaning

No two ash pipes can form a loop during cleaning; only single-pipe open circuit cleaning is allowed. The method involves connecting one end of the ash pipe to the cleaning unit, continuously preparing a certain concentration of cleaning solution in the liquid mixing tank, and then continuously or intermittently injecting it into the ash pipe. This process requires adding cleaning equipment during shutdown, which increases costs.
Chemical Equipment Cleaning in Junan, Linyi, Shandong

Continuous cleaning without downtime

The process involves continuously injecting a specific amount of acidic fluid while simultaneously adding a certain quantity of cleaning corrosion inhibitor and pipeline descaling agent to the ash conveying pipes, conducting an open-circuit cleaning. The primary role of the cleaning additives is to promote the reaction between the acidic fluid and ash deposits within a certain concentration and flow rate, while also enhancing their solubility in water and reducing the occurrence of air blockages, ensuring the quality of ash pipe cleaning.

The procedure is as follows: Before cleaning, first estimate the required acid amount based on the total scale in the pipeline. Then, calculate the acid addition rate and the flow rate of the sludge conveying pipeline by considering the flow rate of the gray water and the acidity. During the cleaning process, take a sample at the sampling point at the front of the gray pipe every 30 minutes to test the acidity and strictly control it by adjusting the flow rate of acid addition. In the later stage of cleaning, take a sample at the end of the gray pipe every 15 minutes to test the pH value. When the pH value reaches a certain level and remains unchanged for 30 minutes, the cleaning can be considered complete.
Chemical Equipment Cleaning - Shandong Linyi, Junan

2. High-pressure water cleaning equipment
High-pressure water jetting is used for cleaning, offering advantages such as high efficiency, low cost, non-damaging to workpieces, non-polluting the environment, easy operation, and safety.
The advantages of high-pressure water technology include:

Steam boiler cleaning, preheater, economizer cleaning, ash removal - Shandong, Rizhao, Lanshan

(1) Excellent Cleaning Quality - The high-pressure water jet cleaning of pipe and heat exchanger interiors effectively removes all scaling and blockages from the inside, revealing the metal surface. With its immense energy and ultra-sonic motion, the high-pressure water jet is fully capable of breaking down hard scaling and blockages without causing any damage to the metal.

Due to the pressure of high-pressure water being less than the compressive strength grade of metal, high-pressure cleaning will not damage the base material being cleaned.
Chemical Equipment Cleaning - Shandong Linyi, Junan

(2) Fast Cleaning Speed: Due to the combined effects of jet washing, wedging, shearing, and grinding, scale can be quickly broken and removed, making the cleaning process several to ten times faster than traditional chemical methods, sandblasting, simple mechanical, and manual methods.

Additionally, parts cleaned with high-pressure water jetting do not require secondary cleaning; however, after chemical cleaning, the surface needs to be rinsed with clean water. Steam boiler cleaning preheater economizer cleaning descaling Shandong Rizhao Lanshan

Chemical Equipment Cleaning - Shandong Linyi, Junan

(3) No Environmental Pollution: As high-pressure water jet cleaning uses pure water as the medium, it does not generate a large amount of dust like sandblasting, shot blasting, or simple mechanical cleaning, which can pollute the atmosphere and harm health. It also does not produce a large amount of waste liquid like some chemical cleaning methods, which can pollute rivers, soil, and water quality. The water jet cleaning with pure water as the medium is odorless, tasteless, and non-toxic. After the spray is atomized, it can also reduce the dust concentration in the work area, allowing atmospheric dust to drop from 80mg/m³ with other methods to below the national safety standards, thus causing no pollution. Steam boiler cleaning, preheater cleaning, economizer cleaning, and ash removal in Shandong Rizhao Lanshan.

Chemical Equipment Cleaning - Shandong Linyi, Junan

3. Pipe Scale: Cleaning of steam boiler economizer, preheater, and ash removal in Shandong, Rizhao, Lanshan

(1) Classified by chemical composition, they can be categorized into carbonate scale, sulfate scale, silicate scale, and mixed scale, etc. The main components of carbonate scale are calcium carbonate and magnesium carbonate; the main components of sulfate scale and silicate scale are calcium sulfate and silicate compounds, respectively; mixed scale is usually a mixture of the above three types.
Chemical Equipment Cleaning in Junan, Linyi, Shandong

(2) Categorized by physical properties, there are two types: hard scale that firmly adheres to the pot shell and tube walls, and loose sediment that is easy to detach.
Lime scale primarily forms due to the salts like calcium and magnesium in the boiler feed water, which precipitate and adhere to the metal surface upon heating. Lime scale has a very low thermal conductivity, approximately 2 to 5 times that of ordinary steel. When lime scale accumulates on the boiler's heating surface, it significantly worsens the heat transfer efficiency and affects the boiler's performance; it can easily cause metal materials to burn due to localized overheating, even leading to pipe explosion accidents; it also accelerates galvanic corrosion, causing pipeline lime scale corrosion and speeding up the damage to the heating surface. Once lime scale forms, it should be promptly removed using mechanical or chemical methods.

Heat Exchanger & Refrigeration Equipment Cleaning - Choose Greentech Chemical for Reliability
