Shuanggou Electric Trolley Conductive Rail, Type行车 Copper Conductor Rail

One. Contact Wire (also known as Motor Car Overhead Wire, Gantry Crane Electric Wire):

1. Trolley Bus Copper Conductors (also known as Double Groove Copper Wire, Bare Copper Wire): CT Series (CT85, CT110, CT120, CT150, CT185, CT200, CT220, CT250). Made from oxygen-free copper, featuring high conductivity and high strength.

2. Copper Alloys Contact Wires: Copper-Silver Alloy CTAH Series (CTAH85, CTAH110, CTAH120, CTAH150, CTAH185)

Copper-magnesium alloy series CTMH (CTMH110, CTMH120, CTMH150)

3. Enclosed steel-aluminum composite trolley wires: GLCN series (GLCN195, GLCN250); 4. Exposed steel-aluminum composite trolley wires: CGLW series (CGLW100, CGLW173, CGLW215)

5. Steel-reinforced aluminum composite electric cables: CGLHD series (CGLHD195, CGLHD260, CGLHJ260)

6. Aluminum alloy trolley wire: CLHA series (CLHA 130, CLHA 170, CLHA 200)

7. Trolley Copper Conductor: Φ6mm to Φ30mm

8. Shuanggou Copper Conductors: 35mm2 - 185mm

9. Safety滑触线

Shuanggou Electric Trolley Conductive Rail, Model of Vehicle Copper Conductive Wire

Two, Hanging Wire Fittings (also known as Hanging Wire Tensioners or Hanging Wire Devices):

1. Electric collector assembly (receiver), collector head, carbon slider, copper wire lead, electric cable copper-aluminum transition (SLT-1, SLT-2), disc-type copper feeder wire clamp.

2. Chain Suspended Assembly, Rigid Suspended Assembly, Armored Hoist Wire, Curved Hoist Wire (-001), Phenolic Hoist Wire (AK-1)

3. Hanging porcelain bottles (CD-1, -1), rigid porcelain bottles (-02), tram needle porcelain bottles (P-6-10-15), chain-suspended porcelain bottles, rigid boards (120mm, 150mm, 300mm), wire pullers (XK-1), hanging plates.

4. Single-line clamps (DXK-1, DXT-1), double-line clamps (DXK-2, BXT-2), connecting wire clamps (BJK-1, BJK-2, BJT-2, BJKT-1), ring clamp wire connectors (KH-1), aluminum feedline clamps (KDL-1), copper feedline clamps (KDT-1), jumper wire clamps (DA-1), terminal line clamps (ZD-1-2-3), suspension wire clamps (DJ-1), wire tube single-line clamps, wire board single-line clamps, chain suspension clamps, steel rope clips (12mm-15mm)

5. Sectional Switches (HHP1-200, HHP1-200-600), Trolley Line Section Insulators (F-1, F-2), Insulators (J-1, J-2, J-4.5), Insulating Strips, Terminal Adjustment Hooks (TJ-12, TJ-16), Cross Hanger Hooks, Single String Walls, Double String Walls.

The CT series electric cables are assembled from components such as oxygen-free copper rods, suspension, insulating gas components, power feed clamps, and collectors. Thanks to its features like oxygen-free copper production, high conductivity, high strength, and long service life, this product is widely used in industries such as railways, coal mines, metallurgy, urban transportation, electric locomotives, and public cranes.
