Clean various heat exchangers, condensers, industrial pipelines, boilers, and power plant equipment condensers - Grean Chemical Co. guarantees cooperation.

Jining Green Chemical Technology Co., Ltd. (简称 Jining Green Cleaning Co.) was established in 2010 and is a specialized company in cleaning various industrial heat exchange equipment. The company boasts comprehensive business philosophy and the capability to develop industrial cleaning technologies, handling cleaning services for industrial, private enterprise, and corporate chemical equipment, power plant equipment, condensers, boilers, and economizers. We also offer air conditioning cleaning, heat exchange equipment cleaning, and mechanical and chemical equipment cleaning services. Additionally, we undertake the cleaning of refrigeration and heating equipment to remove scale.

Jining Green Cleaning Co. offers a wide range of cleaning machines from 10mpa to 250mpa, with dozens in stock and over a dozen chemical cleaning pump stations. Our primary services include power plants, chemical factories, oil mills, food processing plants, corporate entities, heating equipment, and more. The company also provides long-term industrial heat exchanger cleaning and design solutions for industry clients.

Our company has newly acquired domestic cleaning machines and imported cleaning equipment. We have hired experienced technical specialists in the cleaning industry, which has enabled the cleaning of heat exchange equipment to be standardized and standardized.

Air Handling Unit Cleaning in Yantai, Penglai, Shandong

Chemical Cleaning Scale Removal Process

Recirculating Closed Loop Cleaning

Recirculating cleaning utilizes two existing parallel ash piping lines to form a loop, creating a recirculation system with the cleaning pump station. A certain concentration of acidic solution is added, which circulates through the ash water pipes for cleaning. As the acid washing reaches a certain level, the acidic solution is continuously replenished. For short-distance single ash water pipelines, if conditions permit, a temporary pipeline can be laid to form a recirculation loop for cleaning. This process must be carried out while the system is shut down, and it is complex and costly.
Air Handling Unit Cleaning in Yantai, Penglai, Shandong

Breakthrough Cleaning

No two gray pipes should form a loop during cleaning; only a single gray pipe should be used for open-loop cleaning. The method involves connecting one end of the gray pipe to the cleaning unit, continuously preparing a specific concentration of cleaning solution in the mixing tank, and then continuously or intermittently injecting it into the gray pipe. This process requires the addition of cleaning equipment during shutdown, which increases the cost.

Continuous operation cleaning

The process involves continuously injecting a certain amount of acidic solution while operating the ash conveying pipes, simultaneously introducing a specific quantity of ash conveying pipe cleaning inhibitor and pipeline descaling agent. This is an open-circuit cleaning method. The primary function of the cleaning aids is to promote the reaction between the acidic solution and the ash scale at a certain concentration and flow rate, while also enhancing its solubility in water, reducing the occurrence of airlock, and ensuring the quality of ash pipe cleaning.

Operation procedure: Before cleaning, first estimate the required acid amount based on the total scale in the pipeline. Then, calculate the acid addition rate and the flow rate of the ash slurry pipe by considering the flow rate and acidity of the gray water. During cleaning, take samples at the sampling point at the front end of the ash pipe every 30 minutes to test the acidity, and strictly control the acidity by adjusting the flow rate of acid addition. In the later stage of cleaning, take samples at the end of the ash pipe every 15 minutes to test the pH value. When the pH value reaches a certain level and remains unchanged for 30 minutes, the cleaning can be considered complete.
Air Handling Unit Cleaning in Yantai, Penglai, Shandong

2. High-pressure water jet cleaning machinery
High-pressure water jet cleaning offers advantages such as high efficiency, low cost, non-damaging to workpieces, environmental friendliness, ease of operation, and safety.
High-pressure water technology boasts the following advantages.

(1) Excellent Cleaning Quality: The high-pressure water jet cleaning for pipelines and heat exchanger bores can completely remove scale and obstructions from inside the pipes, revealing the metal surface. The high-pressure water jet, with its immense energy and supersonic speed, is fully capable of destroying tough scale and obstructions without causing any damage to the metal.

Since the pressure of the high-pressure water is less than the compressive strength grade of metal, high-pressure cleaning will not damage the substrate being cleaned.
Air Handling Unit Cleaning in Yantai, Penglai, Shandong

(2) Fast Cleaning Speed: Due to the combined effects of jet washing, wedging, shearing, and grinding, scaling can be quickly broken and removed, which is several to ten times faster than traditional chemical methods, sandblasting and shot peening techniques, simple mechanical, and manual cleaning methods.

Components cleaned with high-pressure water jetting do not require secondary cleaning; however, those chemically cleaned need to be rinsed with clean water to remove the surface residue.
Air Handling Unit Cleaning in Yantai, Penglai, Shandong

(3) No Environmental Pollution - As high-pressure water jet cleaning uses pure water as the medium, it does not generate large amounts of dust like sandblasting or simple mechanical cleaning, which can pollute the air and harm health. It also does not produce a large volume of waste liquid like some chemical cleaning methods, which can contaminate rivers, soil, and water quality. The water jet cleaning with pure water as the medium is odorless, tasteless, and non-toxic. After atomization, the spray can also reduce the dust concentration in the work area, lowering atmospheric dust levels from 80mg/m³ using other methods to below the national safety standards. Therefore, it does not cause any pollution.

Air Handling Unit Cleaning in Yantai, Penglai, Shandong

3. Pipe Scale

(1) Classified by chemical composition, they can be categorized into carbonate scale, sulfate scale, silicate scale, and mixed scale. The main components of carbonate scale are calcium carbonate and magnesium carbonate; the main components of sulfate scale and silicate scale are calcium sulfate and silicate compounds, respectively; mixed scale is usually a mixture of the above three types.
Air Handling Unit Cleaning in Yantai, Penglai, Shandong

(2) Categorically classified by physical properties, there are two types: a hard scale that firmly adheres to the pot shell and tube walls, and a loosely textured sediment that is easy to detach.
Lime scale primarily forms due to the salts of calcium and magnesium present in the boiler feed water, which precipitate and adhere to the metal surface upon heating. Lime scale has a very low thermal conductivity, approximately 2-5 times that of ordinary steel. When lime scale accumulates on the boiler's heating surface, it significantly worsens the heat transfer efficiency and affects the boiler's performance; it can also cause metal materials to burn due to localized overheating, potentially leading to pipe explosion accidents; it accelerates galvanic corrosion, causing pipeline lime scale corrosion, and speeds up the damage to the heating surface. Once lime scale forms, it should be promptly removed using mechanical or chemical methods.

Heat Exchanger & Refrigeration Equipment Cleaning - Choose GreenChem for Confidence
