Clean all types of heat exchangers, condensers, industrial pipelines, boilers, and steam power plant condensers. Glan Chemical Co. offers guaranteed cooperation.

Jining Green Chemical Technology Co., Ltd. (abbreviated to Jining Green Cleaning Co.) was established in 2010 and is a professional company specializing in cleaning various industrial heat exchange equipment. The company boasts comprehensive business philosophy and the capability to research and develop industrial cleaning technologies. We undertake cleaning services for industrial, private enterprise, and corporate chemical equipment, power plant equipment, condensers, boilers, and economizers. We also provide air conditioning cleaning, heat exchange equipment cleaning, and cleaning services for machinery and chemical equipment. Additionally, we handle the cleaning and descaling of refrigeration and heating equipment.
Air Handler Coil Cleaning in Yantai, Penglai, Shandong

Jining Green Clean Company stocks dozens of cleaning machines with various models ranging from 10mpa to 250mpa, and over a dozen chemical cleaning pump stations. Our primary services are to power plants, chemical factories, oil refineries, food processing plants, corporate entities, heating equipment, and more. The company also provides long-term industrial heat exchanger cleaning and design solutions to industry clients.

Our company has newly acquired domestic cleaning machines and imported cleaning equipment. We have hired experienced technical specialists in the cleaning industry to standardize and regulate the cleaning of heat exchange equipment.

Antiscalant manufacturer in Dingtao, Heze, Shandong

Chemical Cleaning Scale Removal Process

Recirculating Closed Loop Cleaning

Recirculating cleaning utilizes two existing parallel deslagging pipelines to form a loop, creating a recirculation system with the cleaning pump station. A solution of a certain concentration of acidity is added, which circulates within the slurry pipes for cleaning. As the acidity washes down to a certain level, acid is continuously replenished. For short-distance single slurry pipelines, if conditions permit, a temporary pipeline can be laid to form a recirculation loop for cleaning. This process must be carried out during shutdown, is complex, and has a higher cost.

Open road cleaning

During cleaning, two gray pipes cannot form a loop; only a single gray pipe should be used for open-loop cleaning. The method involves connecting one end of the gray pipe to the cleaning unit, continuously preparing a certain concentration of cleaning solution in the mixing tank, and then injecting it into the gray pipe continuously or intermittently. This process requires adding cleaning equipment during shutdown, which increases costs.

Air Handler Coils Cleaning in Yantai, Penglai, Shandong

Continuous cleaning without shutdown

The process involves continuously injecting a certain amount of acidic solution while the ash pipe is operating normally and not shut down, simultaneously adding a certain amount of ash-pipe-running cleaning inhibitor and pipeline descaling agent, and performing open-circuit cleaning. The primary function of the cleaning aids is to promote the reaction between the acidic solution and the ash scale at a certain concentration and flow rate, while also increasing its solubility in water, reducing the formation of air blockages, and ensuring the quality of ash pipe cleaning.

Operation procedure: Before cleaning, estimate the required acid quantity based on the total scale in the pipeline. Then, calculate the acid addition rate and the flow rate of the sludge conveying pipe by considering the grey water flow rate and acidity. During the cleaning process, collect and test the acidity at the sampling point at the front of the grey pipe every 30 minutes. Adjust the acid flow rate to strictly control the acidity. In the later stage of cleaning, test the pH value at the end of the grey pipe every 15 minutes. When the pH value reaches a certain level and remains unchanged for 30 minutes, the cleaning process can be considered complete.
Air Handler Coil Cleaning in Yantai, Penglai, Shandong

2. High-pressure water jet cleaning machinery
High-pressure water jet cleaning offers high efficiency, low cost, non-damaging to workpieces, environmental friendliness, ease of operation, and safety advantages.
The high-pressure water technology offers the following advantages.

(1) High-quality Cleaning: During the high-pressure water jet cleaning of pipe and heat exchanger interiors, all scaling and obstructions are thoroughly removed, revealing the metal substrate. The high-pressure water jet, with its immense energy and supersonic speed, can completely dismantle hard scaling and obstructions without causing any damage to the metal.

High-pressure water cleaning will not damage the base material being cleaned, as the pressure is less than the compressive strength grade of the metal.

(2) Fast Cleaning Speed - Due to the combined action of abrasive jetting, wedge splitting, shearing, and grinding, scale can be quickly shattered and removed, which is several to tens of times faster than traditional chemical methods, sandblasting, ball-blasting, simple mechanical, and manual cleaning methods.

Additionally, components cleaned with high-pressure water jetting do not require secondary cleaning; however, after chemical cleaning, the surface must be washed with clean water.

(3) No Environmental Pollution: As high-pressure water jet cleaning uses pure water as the medium, it does not generate a large amount of dust like sandblasting or simple mechanical cleaning, which can pollute the atmosphere and harm health. It also does not produce a large volume of waste liquid like some chemical cleaning methods, which can contaminate rivers, soil, and water quality. The water jet, using pure water, is odorless, tasteless, and non-toxic. After atomization, it can also reduce the dust concentration in the work area, lowering atmospheric dust from 80mg/m³ using other methods to below the national safety standards, thus causing no pollution.

Air Handling Unit Cleaning in Yantai, Penglai, Shandong

Pipe

(1) Categorized by chemical composition, they include carbonate scale, sulfate scale, silicate scale, and mixed scale. The main components of carbonate scale are calcium carbonate and magnesium carbonate; the primary components of sulfate and silicate scales are calcium sulfate and silicate compounds, respectively. Mixed scale is typically a mixture of the above three types.

(2) Classified by physical properties, there are two types: scale that firmly adheres to the pot shell and pipe walls, and sediment that is loosely textured and easily dislodged.
Lime scale primarily forms due to the salts like calcium and magnesium in the boiler feed water, which precipitate and adhere to the metal surface upon heating. Lime scale has a very low thermal conductivity, approximately 2 to 5 times less than that of ordinary steel. When lime scale accumulates on the boiler's heating surface, it significantly worsens the heat transfer efficiency and affects the boiler's performance; it can easily cause metal materials to burn due to localized overheating, potentially leading to pipe explosion accidents; it also accelerates galvanic corrosion, causing pipeline lime scale corrosion and speeding up the deterioration of the heating surface. Once lime scale forms, it should be promptly removed using mechanical or chemical methods.

Heat Exchanger and Refrigeration Equipment Cleaning - Choose GreenChem for Confidence
