Clean various heat exchangers, condensers, industrial pipelines, boilers, and steam power plant condensers. Glan Chemical Co., Ltd. offers guaranteed cooperation.

Jining Green Chemical Technology Co., Ltd. (简称 Jining Green Cleaning Co.) was established in 2010 and is a professional company specializing in the cleaning of various industrial heat exchange equipment. The company boasts comprehensive business philosophy and the capability to research and develop industrial cleaning technologies. We undertake cleaning services for industrial, private enterprise, and corporate chemical equipment, power plant equipment, condensers, boilers, and economizers. We also provide air conditioning cleaning, heat exchange equipment cleaning, and cleaning services for machinery and chemical equipment. Additionally, we handle the cleaning of refrigeration equipment and heating equipment for scale removal.
Condenser Cleaning Pre-film in Shandong Heze Chengwu

Jining Grean Cleaning Co. has dozens of cleaning machines ranging from 10mpa to 250mpa and over a dozen chemical cleaning pump stations. Our main services are provided to power plants, chemical factories, oil mills, food processing plants, corporate entities, heating equipment, and more. The company also offers long-term industrial heat exchanger cleaning and design solutions to industry clients.

Our company has newly acquired domestic cleaning machines and imported cleaning equipment. We have hired experienced technical specialists in the cleaning industry, which has enabled the cleaning of heat exchange equipment to be standardized and regulated.

Condenser Cleaning Pre-film Shandong Heze Chengwu

Chemical descaling process:

Recirculating Closed Circuit Cleaning

Recirculating cleaning utilizes two existing parallel ash removal pipelines to form a loop, creating a recirculation system with the cleaning pump station. A certain concentration of acidic solution is added, which circulates through the ash water pipes for cleaning. As the acid washing reaches a certain level, the solution is continuously replenished. For short-distance single ash water pipelines, if conditions permit, a temporary pipeline can be laid to form a recirculation loop for cleaning. This process must be carried out while the system is offline, and it is complex and costly.
Condenser Cleaning Pre-film in Chengwu, Heze, Shandong

Breakthrough Cleaning

No two ash pipes can form a loop during cleaning; only a single ash pipe can be used for open circuit cleaning. The method involves connecting one end of the ash pipe to the cleaning unit, continuously preparing a certain concentration of cleaning solution in the mixing tank, and then continuously or intermittently injecting it into the ash pipe. This process requires additional cleaning equipment during shutdown, resulting in higher costs.
Condenser Cleaning Pre-coating in Shandong Heze Chengwu

Non-stop cleaning

The process involves continuously injecting a specific amount of acidic fluid while simultaneously adding a certain quantity of cleaning inhibitor for the conveying pipe and pipeline descaler, performing open-loop cleaning. The primary function of the cleaning aids is to promote the reaction between the acidic fluid and the ash scale within a certain concentration and flow rate, while also enhancing its solubility in water and reducing the occurrence of air blockage, ensuring the quality of ash pipe cleaning.

The procedure is: Before cleaning, first estimate the required acid amount based on the total scale in the pipeline. Then, calculate the acid addition rate and the flow rate of the descaling agent and pipeline cleaner based on the sludge flow rate and acidity. During cleaning, take samples at the front of the sludge pipe every 30 minutes to test the acidity, and strictly control the acidity by adjusting the acid flow rate. In the later stage of cleaning, take samples at the end of the sludge pipe every 15 minutes to test the pH value. When the pH value reaches a certain level and remains unchanged for 30 minutes, the cleaning process can be deemed complete.
Condenser Cleaning and Pre-film Services in Chengwu, Heze, Shandong

2. High-pressure water jet cleaning machinery
High-pressure water jet cleaning offers advantages such as high efficiency, low cost, non-damaging to workpieces, environmental friendliness, ease of operation, and safety.
Advantages of high-pressure water technology include:

(1) Excellent Cleaning Quality: The high-pressure water jet cleaning for pipes and heat exchanger bores can thoroughly remove all scale and blockages inside, revealing the metal substrate. The high-pressure water jet, with its immense energy and supersonic speed, is fully capable of destroying hard scale and blockages without causing any damage to the metal.

The high-pressure water pressure is less than the tensile strength grade of metal, so high-pressure cleaning will not damage the cleaned substrate.
Condenser Cleaning Pre-film in Shandong Heze Chengwu

(2) Fast Cleaning Speed: Due to the combined action of water jet washing, splitting, shearing, and grinding, scaling can be quickly broken and removed, which is several to ten times faster than traditional chemical methods, sandblasting, ball-shot peening, simple mechanical, and manual cleaning methods.

Components cleaned with high-pressure water jetting do not require secondary cleaning; however, after chemical cleaning, the surface must be rinsed with clean water.
Condenser Cleaning and Pre-film Treatment in Chengwu, Heze, Shandong

(3) No Environmental Pollution: Since high-pressure water jet cleaning uses pure water as the medium, it does not produce a large amount of dust like sandblasting, shot blasting, or simple mechanical cleaning, which can pollute the air and harm health. It also does not generate a large volume of waste liquid like some chemical cleaning methods, which can contaminate rivers, soil, and water quality. The water jet cleaning with pure water as the medium is odorless, tasteless, and non-toxic. After atomization, the emitted jet can also reduce the dust concentration in the working area, lowering atmospheric dust from 80mg/m³ with other methods to below the national safety standards, thus causing no pollution.

Condenser Cleaning Pre-film Shandong Heze Chengwu

3. Pipe Scale

(1) Classified by chemical composition, it can be categorized into carbonate scale, sulfate scale, silicate scale, and mixed scale, among others. The main components of carbonate scale are calcium carbonate and magnesium carbonate; the primary components of sulfate scale and silicate scale are calcium sulfate and silicate compounds, respectively; mixed scale is usually a mixture of the above three types.

(2) Categorized by physical properties, there are two types: hard scale that firmly adheres to the pot and tube walls, and loose sediment that is easy to dislodge.
Scale primarily forms due to the salts of calcium and magnesium present in the boiler feed water, which precipitate and adhere to the metal surface upon heating. The thermal conductivity of scale is very low, around 2 to 5 times that of ordinary steel. When scale accumulates on the boiler's heating surface, it severely impairs heat transfer efficiency, affecting the boiler's performance; it can easily lead to the burnout of metal materials due to localized overheating, even causing tube explosion accidents; it accelerates galvanic corrosion, leading to pipeline scale corrosion and hastening the damage to the heating surface. Once scale forms, it should be promptly removed using mechanical or chemical methods.

Heat Exchanger and Refrigeration Equipment Cleaning - Choose Grean Chemical for Reliability
