Product Introduction

Motion trajectory tracking measurement within a 100-meter visual field

Core Technology

Technical Specifications

The Targe system is a 3D dynamic measurement system that utilizes close-range industrial photogrammetry and visual triangulation methods, based on target point tracking. Targe accurately measures the trajectory, posture, and velocity data of target points in 3D space. Compared to traditional measurement methods (such as displacement sensors, velocity sensors), Compared, the Targe system significantly enhances measurement efficiency, gathers more measurement data, and presents test results in a visual format, aiding customers in better observing and understanding the deformation and motion characteristics of the test object.

Measurement Data

The Targe Wide Field Dynamic Measurement System can be used for testing the vibration and complex motion of dynamic and static components, as well as large structures in three dimensions. The Targe Wide Field Dynamic Measurement System can measure and analyze the following data:

(1) 3D Coordinate

(2) 3D Motion Deformation

(3) Three-dimensional Velocity and Acceleration

(4) 3D Trajectory Measurement

(5) 6-axis measurement

Measurement Results

The Targe Wide Field Dynamic Measurement System is based on image analysis calculations, offering a visual display of measurement results and various analysis methods.

(1) Image

(2) Table

(3) Video

(4) Curve

(5) Custom Data

System Advantages

The Targe system is portable, easy to operate, and requires no complex experimental setup. It effortlessly handles various shapes and sizes of specimens without affecting their performance, making it an ideal tool for structural deformation and motion analysis.

(1) Non-contact real-time measurement, without affecting material properties

(2) Suitable for nearly all materials, from sample and parts to full machine deformation measurement

(3) Measuring range from a few meters to hundreds of meters

(4) Sub-pixel measurement accuracy, 0.01%

(5) Diverse measurement results: data, videos, curves, reports, etc.

(6) Strong environmental adaptability: High and low temperatures, high-speed impacts, vibration, etc.

(7) Traceable Testing Process

Application Scenario

The Targe system boasts online detection, real-time analysis, and real-time control capabilities. It can be widely applied to deformation detection and motion tracking under various operational and loading tests, addressing issues such as complicated sensor placement, low efficiency, and intricate data processing in traditional testing methods.

Large truss structure static and dynamic load deformation detection

(2) Large Building Vibration Test Deformation Monitoring

(3) Bridge and Tunnel Deformation Monitoring

(4) Wind turbine blade deformation detection scenarios
