The LXC-50 316L stainless steel centrifugal extraction unit is a new, rapid, and efficient liquid-liquid extraction separation equipment. It boasts higher separation efficiency than traditional extraction equipment, such as extraction basins and towers, and is more conducive to achieving continuous production.

Centrifugal extractors use an electric motor to drive the drum to rotate at high speed. The two mixed liquids to be separated are mixed and transferred by the shearing force generated by the stirrer, and then quickly separated by the centrifugal force produced by the high-speed rotation of the drum.

Centrifugal extraction units can be used individually or in multi-stage series for countercurrent extraction, offering high mass transfer efficiency, short two-phase residence time, and minimal retention. They are easy to operate and can be adjusted for speed, flow ratio, and mixing intensity as needed.

To meet customer needs, Zhengfen Distillation offers extraction equipment consulting and services: from initial communication, planning, and design of process objectives or operational conditions, to customized production and manufacturing, helping you build the ideal extraction equipment, giving you greater peace of mind and convenience. Welcome to inquire!

Hotline: 153-8076-6707!

Blending process

Light and heavy phase materials are fed into the mixing zone of the equipment via the feed inlet of the centrifugal extraction unit at the required ratio by the feed pump, driven at high speed by the motor, which quickly mixes and disperses the light and heavy phases, thereby completing the mixing mass transfer process.

Separation process

The mixed liquid enters the drum under the action of the vortex disk or feeder. Within the cavity formed by the drum's web, the mixed liquid quickly synchronizes with the drum's rotation. Under the force of centrifugal force, the denser heavy phase liquid gradually moves away from the drum center and towards the drum wall during its upward flow; conversely, the lighter phase liquid, with lower density, moves away from the drum wall towards the center. After clarification, the two-phase liquids pass through their respective weir plates into the collection chamber and exit through the heavy and light phase outlets, completing the two-phase separation process.

Equipment Features

High mixing efficiency and extraction effect: Can flexibly match mixing structures according to different material system requirements, achieving efficient extraction.

♦ Effective two-phase separation: The equipment separates water phase and organic phase using centrifugal force, ensuring quick and stable separation while avoiding interference from human factors.

♦ Low online liquid holding capacity: The internal liquid holding capacity of the equipment is small, for example, the liquid holding capacity of a 6m³/h processing capacity equipment can be 35L.

♦ Small amplification effect of equipment: The equipment separates using centrifugal force and employs precise mixing, making it a typical process intensification device with a small amplification effect.

♦ Energy-saving and environmentally friendly: Low power consumption equipment, fully enclosed, high-efficiency and energy-saving environmental protection equipment.

Small equipment footprint

Application Fields: Fine Chemical Industry, Biofermentation Industry, Petrochemical Industry, Hydrometallurgy Industry, New Energy Battery Industry, Environmental Protection Industry

Wastewater Treatment, Fermentation Broth Extraction, Solvent Extraction and Recovery, Lithium Battery Recycling, Rare Metal Extraction, Oil-Water Separation, Brine Lithium Extraction, Material Purification, Ester Liquid Water Washing
