The PEL 1000E/XU series DC electronic loads are high-power programmable DC electronic load systems integrated into 19" rack-mounted or enclosed cabinets. Composed of programmable DC electronic load modules, these high-power density products can be easily paralleled to achieve an output power of up to 600KW, with voltage up to 1200VDC and current up to 2400ADC. Their modular design and standardized load and protection modules make them economically and flexibly adaptable to various user requirements.

Key Features:
Voltage Range: 0~1200V available
■ Current Range: 0~2400A Available
Voltage Accuracy ≤ 0.05% F.S
Current Accuracy ≤ 0.1% F.S
■ Parallel multi-machine power can be expanded up to a maximum of 600KW
Data sampling rate up to 1kHz, enabling voltage and current data and curve analysis
■ Programming speed: 50 kHz, sampling speed: 500 kHz
■ Instant overload capability, exceeding twice the rated power
High precision/high stability
Master-slave control function
■ Comprehensive protection features: Overvoltage, overcurrent, overtemperature, current limiting, power limiting, reverse polarity, power-off memory, etc.
Multiple working modes: CC, CV, CR, CP, CRD, CPD, CV+CC, CR+CC, CP+CC, and more operation modes.
Load effect, OCP, OPP, LED simulation, ESR, battery discharge, and various other testing functions
Standard RS-232/RS-485/LAN/USB
Color display control panel, capable of showing actual values, set values, status, and alarm information
