Bend classification methods are divided based on their radius of curvature, into long-radius bends and short-radius bends. Long-radius bends refer to those with a radius of curvature equal to 1.5 times the pipe's outside diameter, denoted as R = 1.5D. Short-radius bends refer to those with a radius of curvature equal to the pipe's outside diameter, denoted as R = D. In this formula, D is the bend diameter, and R is the radius of curvature. When classified by pressure rating, there are approximately seventeen types, which are the same as American pipe standards, including: Sch5s, Sch10s, Sch10, Sch20, Sch30, Sch40s, STD, Sch40, Sch60, Sch80s, XS; Sch80, Sch100, Sch120, Sch140, Sch160, XXS, with STD and XS being commonly used. By angle, there are 45-degree bends, 90-degree bends, and 180-degree bends. This results in a wide variety of bend types. When placing an order, the order form often uses the following notation: for example, "LR STD 90o 8" indicates a long-radius bend with a STD pressure rating and a 90-degree bend of 8 inches; or, "SR XS 45o 4" denotes a short-radius bend with an XS pressure rating and a 45-degree bend of 4 inches. The above is an overview of bend classification.
