Model: ZJX-2X1250
ZJX-2X1250Slitting machine set, mainlyUsed for metal coil cutting, such as cold and hot rolled steel strips, stainless steel, copper, aluminum, galvanized, color coated, etc., the production line is mainly used by steel processing plants, rolling steel plants, electrical industries, automotive, stamping parts, etc.Fully Automatic High-Speed longitudinal Slitting LineComposed of operations such as unrolling, material positioning, longitudinal cutting, and winding (reeling), this is a fully automatic, high-speed, high-capacity longitudinal cutting line.
Model and Technical Specifications
Model | ZJX-3X650 | ZJX-2x1250 | ZJX3X1600 | ZJX-4X1600 | ZJX-6X1600 |
Material | Cold rolled, hot rolled, stainless steel coils, galvanized coils, color coated coils, aluminum coils, pickled coils, copper coils | ||||
Thickness | 0.3-3 mm | 0.2-2 mm | 0.3-3 mm | 0.5-4 mm | 0.5-6mm |
Width | 150-650 | 500-1250 | 500-1250 | 500-1250 | 500-1250 |
Roll Weight | 5T/10T | 10T/15T | 15T/20T | 15T/20T/25T | 20T/25T |
Line speed | 100/120m/min | 120/150m/min | 120/150m/min | 100/120m/min | 60/80/100m/min |
Number of Cut Strips | 6-15Stripe | 6-20Thread | 6-25Thread | 6-30Stripe | 6-30Thread |
Cutting Precision | ±0.05mm | ±0.05mm | ±0.05mm | ±0.1mm | ±0.1mm |
Production line layout (left: raw material input)
