I. Product Features:

High/Low Temperature Windless Test Chambers are suitable for defense industry, aerospace industry automation components, automotive parts, electronic and electrical components, plastics and chemical industry, food industry, pharmaceutical industry, home entertainment audio-visual equipment, large-size LCD televisions, notebooks, etc.Computers, desktop computers, gaming consoles, audio equipment, automotive electronics, and related products with heat aging resistance, cold resistance, and dry resistance.

II. Product Details:

3. Complies with Execution Standards:

IEC-68-2-2 Test Method B: Specification for dry heat without forced air circulation

2. GB 2423.2-2008 Environmental Tests for Electrical and Electronic Products - Part 2

3. GB2423.2-810 (High Temperature Test for Test Samples with Gradual Temperature Rise in Heat Dissipation Test) - No forced air circulation test required.

4. GB2423.2-89 3.1.1: Test conditions without forced air circulation can well simulate free air conditions.

5. GB2423.2 High Temperature Test, Test B. GB/T2423.34-2005 High, Low, Temperature Combination Cycling Test.

4. Technical Specifications:

Temperature Range: -40℃/-30℃/-20℃/0℃/+20℃/~+100℃ (user's choice)

2. Heating Time: Room Temperature (RT) to +100℃ < 45 min

3. Cooling Time: Room Temperature (RT) to -30℃ within less than 55 minutes

4. Stability Control: ±0.5℃

5. Uniformity of Distribution: ±1.5℃

Section 5: Equipment Material and Structure: Overall, the structure is body-type

1. Inner Box Material: SUS 304# Stainless Steel Sheet

2. Outer Carton Material: Special Corrosion-Resistant Painted Cold Rolled Steel

6. Model and Operating Internal Dimensions: (User Selection)

ZT-HD-80L 40"W x 50"H x 40"D

ZT-HD-120L - Width 50 x Height 60 x Depth 40 cm

ZT-HD-150L - Width 50cm x Height 60cm x Depth 50cm

ZT-HD-225L 60W x 75H x 50D cm

ZT--HD306L 60W x 85H x 60D cm

ZT-HD-408L 60W x 85H x 80D cm

ZT-HD-800L  Width 100xHeight 100xDepth 80cm

ZT-HD-1000L 100W x 100H x 100D cm
