Imaging Colorimeter Technical Specifications
SS-1000XImaging ColorimeterTest requirements for various lighting components such as luminous push buttons, illuminated keyboards, screen backlights, etc., applicable to industries like automotive, display, lighting, and electronics, accompanied by user-friendly software design. Equipped with a Canon fixed-focus lens, it offers features like automatic focus, customizable exposure area, brightness detection, and color coordinates xy analysis. The test needs for lighting components in automotive, display, lighting, and electronics industries are met with user-friendly software. The Canon fixed-focus lens allows for automatic focus and electronic aperture selection, with three different aperture settings (large, medium, and small) to achieve brightness adjustments across three orders of magnitude, greatly enhancing the brightness measurement range.
Performance Parameters:Pixel size 3.45um x 3.45um, 4/3-inch CMOS image sensor with high-precision XYZ, V(λ) filters; effective pixels 16 million, resolution @ frame rate 4112x4112 max @ 23.5fps, 12-bit AD width, point matrix capable of capturing the entire scene: measuring the brightness of each pixel point simultaneously.
Pixel Capture:Automatic, single-point, multi-point, multi-point connection, circular, square, polygonal, elliptical, curved, etc.
Test Parameters:Color coordinates x, y, Brightness, Brightness Uniformity, Maximum Value, Minimum Value, Average Value, Brightness Distribution Curve, Brightness Pseudocolor
Key Features:
1. High-Precision Measurement: Filtered XYZ camera that strictly matches the human eye's visual function V(λ), capable of accurately obtaining real and precise brightness data.
2. Rich Software Features: Equipped with functions for uniform distribution of brightness and chroma in single-point, multi-point, and area pseudo-color maps, with adjustable upper and lower limits for each parameter.
3. Exposure Area: Can set exposure area of any pixel size to move
4. Supports secondary calibration feature
5. Rich Interface: Equipped with input/output IO interfaces, capable of triggering tests with customers' PLCs and other automation equipment, providing PASS/NG indicators for pass/fail status, and also offering SDK software packages developed by third parties.
Primary Applications:Imaging chromameters that cater to the testing needs of various luminous devices in industries such as automotive, display, lighting, and electronics, with user-friendly software design. Equipped with high-precision XYZ filters that match the CIE human visual function, 16-megapixel resolution, and the option to choose different models with lenses ranging from 12mm to 50mm focal lengths based on the user's application and requirements. This enables laboratory or on-line automated testing for products across various industries, such as automotive illuminated buttons, glowing keyboards, screen backlights, and more.
Primary Applications: Monitor, Car Dashboard, Car Ambiance Lighting, Keyboard Backlight, Projector, Road Illumination, Switch Display Panel, Indicator Panel, Car Button Backlight, Street Lighting, Luminescent Fiber, etc.
CIE 117-1995 Interior Lighting Discomfort Glare CIE 112-1994 Glare Evaluation System for Outdoor Sports Areas and Zones CIE 140-2000 Road Lighting Calculations
GB 50034-2013 Standard for Design of Building Lighting CJ 145-2015 Standard for Design of Urban Road Lighting GB 7793-2010 Hygienic Standard for Natural Light and Lighting in Classrooms of Primary and Secondary Schools JG 1153-2016 Standard for Design and Inspection of Lighting in Sports Facilities Other Glare-Related Standards
GB4599-2007, QC/T413 Automotive Ambiance Light Test Standard, Fire Emergency Lights, New National Standard GB17945-2010, Automotive LED Headlights GB 25991-2010
