Section 2: Fire Emergency Light Illumination Test Technical Specifications
Fire Emergency Light Illumination Test SS-1000XImaging colorimeters are used for testing various luminous devices such as illuminated buttons, keyboards, and screen backlights in industries like automotive, display, lighting, and electronics. The accompanying software is designed with user-friendliness in mind. Equipped with a Canon fixed-focus lens, it offers features such as automatic focusing, customizable exposure areas, brightness detection, and analysis of color coordinates xy. The testing requirements for luminous devices like illuminated buttons, keyboards, and screen backlights in the automotive, display, lighting, and electronics industries are met with the software's user-friendly design. The Canon fixed-focus lens allows for automatic focusing and electronic aperture selection, with three different aperture sizes enabling brightness adjustments across about three orders of magnitude, significantly enhancing the brightness measurement range.
Performance Parameters:3.45um x 3.45um pixel size, 4/3-inch CMOS image sensor with high-precision XYZ, V(λ) filters; 16 million effective pixels, resolution of 4112x4112 at 23.5fps, 12-bit AD width, point matrix capable of capturing the entire scene: measuring the brightness of each pixel simultaneously.
Pixel Capture:Automatic, Point, Multi-point, Circular, Square, Polygon, Ellipse, Curves, etc.
Test Parameters:Color coordinates x, y, brightness, brightness uniformity, maximum, minimum, average, brightness distribution curve, brightness false color
Key Features:
1. High-Precision Measurement: Filtered XYZ camera strictly matching the human eye's visual function V(λ), capable of accurately obtaining true and precise brightness data.
2. Rich Software Functions: Equipped with functions such as uniform brightness and chromaticity distribution pseudo-color maps for single-point, multi-point, and area, with adjustable upper and lower limits for each parameter.
3. Exposure Area: Can set exposure area of any pixel size to move
4. Supports secondary calibration feature
5. Rich Interface: Equipped with input/output IO interfaces, capable of triggering tests with customers' PLCs and other automation equipment, providing PASS/NG indicators for pass/fail status, and also offering SDK software packages developed by third parties.
Main Applications:Imaging chromameters, designed to meet the testing requirements of various luminous devices in industries such as automotive, display, lighting, and electronics, with user-friendly software. Equipped with high-precision XYZ filters that match the CIE human visual function, 16-megapixel resolution, and the option to choose different models and lenses with focal lengths ranging from 12mm to 50mm based on the user's application and needs. This enables laboratory or online automated testing for products across various industries, such as automotive illuminated buttons, glowing keyboards, and screen backlights.
Primary Applications: Monitor, Car Dashboard, Car Ambience Lighting, Keyboard Backlight, Projector, Road Illumination, Switch Display Panel, Indicator Panel, Car Button Backlight, Street Lighting, Luminescent Fiber, etc.
CIE 117-1995 Indoor Lighting Discomfort Glare CIE 112-1994 Glare Evaluation System for Outdoor Sports Fields and Areas CIE 140-2000 Road Lighting Calculations
GB 50034-2013 Standard for Design of Building Lighting, CJ 145-2015 Standard for Design of Urban Road Lighting, GB 7793-2010 Hygienic Standards for Daylighting and Lighting in Classrooms of Primary and Middle Schools, JG 1153-2016 Standard for Design and Testing of Lighting in Sports Facilities, Other Glare-Related Standards
GB4599-2007, QC/T413 Automotive Atmosphere Light Test Standard, Fire Emergency Lights, New National Standard GB17945-2010, Automotive LED Headlights GB 25991-2010
