HP350FR Infrared Spectral Irradiance Meter

HP350FR Infrared Spectral Irradiance MeterIt's a new-generation light source color testing instrument, integrating advanced microspectrometer, embedded operating system, and microcomputer technology.Convenient to carryQuick and convenient, simple, and more suitable for on-site application scenarios, this parameter testing and verification is adaptable. Sampling measurements of light source parameters can be conducted anytime, anywhere, and can also be connectedPC Software TestingEfficiently analyzes and processes test data, featuring linear measurement and accuracy, widely used in field lighting measurement for homes, shopping malls, schools, factories, greenhouses, outdoors, and various light sources. Also applicable in the research and development of light source products and production line quality control.

Main Applications:

(1) Based on Standards:

Lighting: GB55016-2021 Building Lighting CIE1931, CIE1960, CIE1976, GB/T5700-2008, GB/T 36979

(2) Basic Measurement Functions:

Key Measurement Parameters: Radiant Power, Color Coordinates (x, y, u, v, u', v'), Wavelength, Color Temperature (CCT), Luminous Flux, Color Rendering Index (Ra, Ravg), Color Tolerance (SDCM), Color Purity, Color Saturation (Rg), Color Fidelity (Rf), Color Quality Score (CQS), Luminance to Chrominance Ratio (S/P), Transmittance, etc.

(1) Main Applications

1. A variety ofInfrared light sourceSpectral and energy intensity, spectral power distribution

2. Commercial lighting, indoor lighting, outdoor lighting.

2. Biological Lighting (plant grow lights, plant factories, etc.), greenhouse tunnels;

3. Research and production development of various light sources.

4. Meteorology and agricultural production sector;

5. Research and development of lighting fixtures, supplemental plant growth lights, and quality control of production lines

6. Research, academic exchange, and studies

(1) Product Advantages

1. Communication Method: USB

2. Multiple display options: Computer, IPS Touchscreen

3. Ergonomic hand-held design with easy and convenient operation.

(II) Core Components

1. TCD1304DG CCD detector with anti-reflective coating, achieving quantum efficiency curve in the illuminated area with a wavelength range of 350-800nm

2. Enhanced Coating Grating: Line Count: 1200 lines, Sparkling Wavelength: 300nm, Spectral Response: 200-1100nm

3. Enhanced collimating lens, focusing lens

4. 16-bit high-speed AD sampling

5. High-precision stable operational circuit

6. High-precision optical path, minimal scattered light, elimination of higher-order diffraction spectra (equipped with a cloud spectrum filter system)

（III). Testing Advantages

1. Comparative testing, transmission ratio testing, parameter comparison (tumble and lock modes)

2. Scheduled testing and saving (optical attenuation test verification available)

3. Tunable wavelength for easy search (single band is more convenient for viewing and analysis)

4. One-click testing and sharing (via朋友圈, 微博, forums, etc.) on APPs and mini-programs

5. Test Result Adjustments (Coefficient Adjustments for Test Results in Different Scenarios and Environmental Changes)
