1. Fire Emergency Light Testing Lighting Technical Specifications
Fire Emergency Light Testing Illumination SS-1000G Imaging TypeLuminometers are used in lighting research, streetlight road brightness testing, light environment testing, classroom lighting, stadium lighting, tunnel lighting, and display surface brightness analysis, among others. The testing includes parameters such as the brightness of any point on an image, average, maximum, and minimum brightness within any range, and isometric color maps.
Performance Parameters: Pixel size 3.45um x 3.45um, 4/3-inch CMOS image sensor with high-precision V(λ) filter matching; Effective pixels 16 million, resolution @ frame rate 4112x4112 max @ 23.5fps, AD width 12-bit dot matrix, capable of capturing the entire scene: simultaneously measuring the brightness of each pixel point.
Pixel Capture: Automatic, Single, Multi-point, Multi-point Connection, Circular, Square, Polygonal, Elliptical, Curved, etc.
Test Parameters: 1. Brightness (cd/m2), Color Coordinates (xy), Maximum, Minimum, Average, Uniformity, Brightness Distribution Curve
Key Features:
1. High-Precision Measurement: Filters that precisely match the human visual function V(λ), enabling accurate acquisition of real and accurate brightness data.
2. Rich Software Functions: Equipped with functions such as uniform distribution of brightness and chroma in point, multi-point, and area pseudo-color maps, with parameters adjustable for upper and lower limits.
3. Exposure Area: Can set exposure area of any pixel size to move
4. Supports re-calibration feature
5. Rich Interface: Equipped with input/output IO interfaces, capable of triggering tests with customers' PLC and other automation equipment, providing PASS/NG indicators for pass/fail status, and offering SDK software packages for third-party development.
Primary Applications: Point光源, Surface光源, Emergency lighting, Buoy lights, Urban illumination, Tunnel lighting, Automotive ambiance lighting, Roadway brightness, Landscape lighting, Dashboard brightness, Display screen brightness, Light sources and luminous devices, Cinema and television, Traffic signal signs, Architecture, Atmospheric luminance, and other fields requiring brightness testing, finished LED lighting product inspection, and LED lighting uniformity inspection.
CIE 117-1995 Indoor Lighting Discomfort Glare, CIE 112-1994 Glare Evaluation System for Outdoor Sports Areas and Fields Lighting, CIE 140-2000 Road Lighting Calculations
GB 50034-2013 Standard for Building Lighting Design, CJ 145-2015 Standard for Urban Road Lighting Design, GB 7793-2010 Hygienic Standards for Lighting in Primary and Middle School Classrooms, JG 1153-2016 Standard for Lighting Design and Inspection of Sports Venues, Other Glare-Related Standards
GB4599-2007, QC/T413 Automotive Ambiance Light Test Standard, Fire Emergency Lights New National Standard GB17945-2010, Automotive LED Headlights GB 25991-2010
Section 3: Performance Specifications
Parameter Name Parameter Indicator
Optical 4/3"
Sensor Model COMS
Camera Type Y Camera
Pixel size 3.45μm x 3.45μm
16.0 megapixels effective
Frame exposure method
Resolution @ Frame Rate: 4112x4112 max @ 23.5 fps
Signal-to-Noise Ratio 40dB
Dynamic Range: 73.6 dB
Sensitivity 1: 146 mV
AD width: 12 bits
Output pixel width: 12-bit
Continuous/Soft Trigger/Hardware Trigger Collection Mode
Maximum Gain (Times): 250
The exposed area can be set to move in any pixel size.
Exposure Time Range (ms): 0.0141 ~ 29,546.9
Frame Buffer: 128MB
Lens interface available with CSC port option
Data Interface USB 3.0
Power Supply: 5V
Power < 2W
Dimensions: 155*131*126mm
500g
Measurement Range: 0.01 - 100,000 cd/m²
Measurement Accuracy (±4% of reading ±1 reading) under A light source
Measurement repeatability ±0.1%
12mm lens focal length
Filter match for human eye visual function V(λ) of sensor type
