Ultraviolet Spectroradiometer Equipment Details
One,HP350UV Wireless Intelligent UV Spectrophotometer
The HP350UV Wireless Intelligent UV Spectrophotometer is a new-generation handheld wireless UV light source光度计 and chromaticity tester, integrating advanced microspectrometer, embedded operating system, and microcomputer technology.Convenient to carry testMore convenient, simpler, and better suited to on-site application scenarios, the parameter testing and verification. Sampling measurements of light source parameters can be conducted anytime, anywhere, and can also be connectedPC Test Print ReportEfficiently analyzes and processes test data, with measured linearity and accuracy.
As per standard:
GB 28235—2020、GB 28235-2011、GB24147-2009、GB23112-2008、GB33374-2016 、GB30671-2014
Basic Measurement Parameters:
Irradiance (mw/m²)2Wavelength, half-width, UVA, UVB, UVC, transmission ratio, etc.
(I) Main Applications
1. UV blocking performance tests for architectural films, solar films, insulating glass, etc.
2. Measurement of the radiation intensity from ultraviolet sources (sunlight, UV lamps, etc.)
3. UV sterilization, curing
4. Meteorology and agricultural production sector
5. Research and development of UV products, production line quality control, etc.
6. UV sterilization lamps, mosquito traps, shoe factories, leather goods factories, etc.
Section 2: Special Applications
Hospitals, disease control centers, pharmaceutical factories, food and drug administration, pharmaceutical manufacturing, healthcare, disease control, dyeing and printing, water disinfection, UV curing, food and drug hygiene. UV disinfection lamps used in hospitals and disease control centers can effectively kill a wide range of microorganisms.
Section 3: Textile Industry
Textiles, fabrics, sun protective clothing, cosmetics UV protection testing - UV index rating, UV protection factor UPF
(4) Core Components
1. UV-enhanced TCD1304DG CCD detector with anti-reflective coating, achieving a quantum efficiency curve in the UV range with a wavelength range of 150-1100nm.
2. UV-enhanced coated grating: Line count: 1200 lines,闪耀wavelength 300nm, spectral response 160-800nm
3. UV-enhanced collimating mirrors, focusing lenses
4. 16-bit High-Speed AD Sampling
5. High-precision stable operating circuit
6. High-precision optical path, minimal scattered light, elimination of higher-order diffraction spectra (equipped with a cloud spectrum filter system)
（Section 3: Testing Advantages
1. Comparative testing, transmission ratio testing, parameter comparison (tumbling and locking modes)
2. Scheduled testing and automatic saving (optical attenuation test verification available)
3. Tunable wavelength for easy search (single band offers greater convenience for viewing and analysis)
4. Test Result Adjustments (coefficient corrections for test results in different scenarios and environmental changes)
II. Optical Path Characteristics (Fiber Spectrometer Structure)
1. Multiple optical inputs: Direct cosine correction into the slit or through SM905 fiber optic (with cosine correction).
2. Wavelength Range: 200-400 nm
3. Spectral Resolution: ±0.2 nm, Wavelength Resolution
4. Luminous intensity linearity ±0.3%
5. Scattered Light: <0.1%
6. Luminous probe cosine correction: Error ≤5%, Non-linearity ≤1%.
7. Absolute Fatigue Error: ≤2%
8. Long wave response error: ≤15%
9. Relative Indication Error: ±5%
10. Zero-value error: ±1% (FS)
11. Range: Automatic ±1% Error
12. High-speed data collection, integral time: millisecond-level;
13. Focal length 42.5mm; symmetrical non-intersecting H-T optical path.
14. Communication Methods: USB Communication, Bluetooth, 485, 232 (HP250 Open Communication Protocol)
15. Dimensions: 80mm x 80mm x 60mm
16. Utilizing advanced microspectrometer technology, offering higher precision than traditional probe testing.
17. Compatible with computer software for testing, capable of connecting to a computer to print test reports.
18. Color LCD display with a user-friendly graphic interface, capable of displaying spectral power distribution waveforms; (HP350UV Wireless Version)
19, 5-inch IPS Touchscreen (HP350UV Wireless Version)
16. Integrated 4200mAh lithium battery, with over 12 hours of extended use
