HP350UVS Hangzhou Dual-Wavelength UV Spectral Irradiance Meter
HP350UVS Hangzhou Dual-Wavelength UV Spectral Irradiance MeterIt is a new-generation handheld wireless ultraviolet light source photometer and chromometer, integrating advanced microspectrometer, embedded operating system, and microcomputer technology.Convenient to carry and testMore convenient, simpler, and better suited to on-site application scenarios, with parameter testing, analysis, and verification. Sampling measurements of light source parameters can be conducted anywhere, anytime, and can also be connectedPC Test Print ReportEfficiently analyzes and processes test data, with measurement linearity and accuracy capabilities.
Based on Standard:
GB 28235—2020、GB 28235-2011、GB24147-2009、GB23112-2008、GB33374-2016 、GB30671-2014
Basic measurement parameters:
Irradiance (mw/m²)2Wavelength, half-width, UVA, UVB, UVC, transmission ratio, etc.
(1) Main Applications
1. UV blocking performance tests for architectural films, solar films, insulating glass, etc.
2. Measurement of the radiation intensity of ultraviolet sources (sunlight, UV lamps, etc.)
3. Ultraviolet disinfection, curing;
4. Meteorology and agricultural production sector
5. Research and development of UV products, production line quality control, and other stages
6. UV sterilization lamps, mosquito traps, shoe factories, leather goods factories, etc.
(II) Special Applications
Hospitals, disease control centers, pharmaceutical factories, food and drug administration, pharmaceuticals, healthcare, disease control, dyeing, water disinfection, ultraviolet curing, food and drug hygiene. Ultraviolet disinfection lamps used in hospitals and disease control centers can effectively kill a wide range of microorganisms.
Section 3: Textile Industry
Textiles, fabrics, sun protective clothing, cosmetic UV protection testing - UV index rating, Ultraviolet Protection Factor (UPF)
(4) Core Components
1. Enhanced UV TCD1304DG CCD detector with anti-reflective coating, achieving quantum efficiency curve in the UV range with a bandwidth of 150-1100nm.
2. UV-enhanced coated grating: Line count: 1200 lines,闪耀 wavelength: 300nm, Spectral response: 160-800nm
3. UV-enhanced collimating mirrors, focusing lenses
4. 16-bit high-speed AD sampling
5. High-precision stable operational circuit
6. High-precision optical path, minimal scattered light, elimination of higher-order diffraction spectra (equipped with a cloud spectrum filter system)
（III). Test Advantages
1. Comparative Testing, Transmittance Testing, Parameter Comparison (Rolling and Locking Modes)
2. Scheduled testing, scheduled saving (optical attenuation test verification available)
3. Tunable wavelength for easy search (single band offers more convenient viewing and analysis)
4. Test Result Adjustments (coefficient corrections for test results in different scenarios and environmental changes)
