Hangzhou Double Color - HP350UV - Upgrade Content as Follows
1. Enhanced ergonomics for handheld devices (added grip curve, ultra-thin design, lighter weight) *Discontinue old brick phones.
2. The system upgrade employs a more open-source Linux system with code, better aligning with the application design of smart products, providing endless space for future instrument upgrades. It has abandoned the old chip's barebones interface system.
3. Chip upgrade from the old STM32 chip to a high-speed CPU processor, doubling the signal collection speed and ensuring more precise data calculations.
4. Touchscreen has become the mainstream for mobile color displays, offering more realistic graphics, smoother touch and usage, a more rational interface design, and an enhanced experience.
5. Optimize and upgrade the optical and electrical paths to ensure more precise test results, guaranteeing the repeatability and consistency of the tests.
A. Product Description:
The HP350UV series is the latest generation of portable light color testing instruments, integrating advanced microspectrometer and microcomputer technology. It brings the previously bulky lab equipment to the production line, enabling online color testing and significantly enhancing the production efficiency of LED manufacturers.
Hangzhou Double Color - HP350UV Ultraviolet Spectral Irradiometer Technical Specifications and Indicators
● Utilizing *'s microspectrometer technology, offering higher precision than traditional probe testing.
● Measureable parameters include color temperature, chromaticity coordinates (x, y, u, v), color rendering index, wavelength, color tolerance, luminance, etc.
● Color LCD display, with a clear graphic interface, capable of displaying spectral waveforms and color tolerance ellipse diagrams.
● Powered by high-performance lithium batteries, reusable.
● Spectral Mode: Telecentric Splitter Non-symmetric CT Spectral System
● The sensor features high precisionUltraviolet CCD；
● Spectral Bandwidth (FWHM): 2 nm
5.0-inch IPS Full HD Color LCD Touch Screen
● UV irradiance test range: 1-200,000 L uW/cm²; resolution: 1 uW/cm²
● Wavelength Measurement Range: 200nm - 400nm
Wavelength Accuracy: ±0.5nm
Measurable Parameters:
● Ultraviolet Irradiance uW/cm²
● Ultraviolet Hazard Irradiance uW/cm²
●UVA(uW/c㎡)
●UVB(uW/c㎡)
●UVC(uW/c㎡)
● Central Wavelength, Peak Wavelength, FWHM (Full Width at Half Maximum), Center Wavelength, Centroid Wavelength
● Additional functional parameters available for customization
Equipment Features
● LIUX Operating System Platform
● Compact and lightweight, easy to carry
5.0" IPS high-definition LCD touch screen, easy and convenient to operate.
● 4000mAh high-capacity battery, provides over 10 hours of continuous use per charge.
Standard with a 4G high-capacity data storage card, capable of storing over 30,000 records.
The telecentric cross asymmetric CT spectral system boasts excellent measurement linearity and accuracy.
Combines spectral, luminance, and chromaticity measurement functions into one.
Self-developed LIUX operating system platform with a user-friendly interface and simple, smooth operation.
