Handheld Infrared Spectrophotometer Device Details

One,HP350FRW Portable Handheld Infrared Spectrophotometer光度计

The HP350FRW Fiber Spectrometer is the latest generation of light source and color testing equipment, integrating advanced microspectrometer technology, embedded operating systems, and microcomputer technology.Convenient to carryQuick and convenient, simple, and more suitable for on-site application scenarios, the parameter testing and verification. Sampling measurements of light source parameters can be conducted anywhere at any time, and can also be connectedPC Software TestingEfficiently analyze and process test data, featuring linear measurement and accuracy, widely used in field lighting measurement for homes, shopping malls, schools, factories, greenhouses, outdoors, and various light sources. Also applicable to research and development of light source products and production line quality control.

Main Applications:

(1) Based on the standard:

Lumination: GB55016-2021 Building Lighting CIE1931, CIE1960, CIE1976, GB/T5700-2008, GB/T 36979

(2) Basic Measurement Functions:

Key Measurement Parameters: Radiant Power, Color Coordinates (x, y, u, v, u', v'), Wavelength, Color Temperature (CCT), Luminous Flux, Color Rendering Index (Ra, Ravg), Color Deviation (SDCM), Color Purity, Color Saturation (Rg), Color Fidelity (Rf), Color Quality Score (CQS), Luminance to Darkness Ratio (S/P), Transmittance, etc.

(1) Main Applications

1. VariousInfrared light sourceSpectral and energy intensity, spectral power distribution

2. Various commercial lighting, indoor lighting, and outdoor lighting.

2. Biological Lighting (plant grow lights, plant factories, etc.), greenhouse tunnels.

3. Research and production development of various light sources.

4. Meteorology and agricultural production sector

5. Research and development of lighting fixtures, supplemental plant growth lamps, and production line quality control

6. Research, academic exchange, and studies

(I) Product Advantages

1. Communication Method: USB

2. Various display options: PC, IPS touch screen

3. Ergonomic handheld design for ease and convenience of use.

(II) Core Components

1. TCD1304DG CCD detector with antireflective coating, achieving quantum efficiency curve in the illumination area with a spectral range of 380-1050nm

2. Enhanced Coating Grating: Line Count: 1200 lines, Shimmer Wavelength: 300nm, Spectral Response: 200-1100nm

3. Enhanced Collimating Mirrors, Focusing Lenses

4. 16-bit High-Speed AD Sampling

5. High-precision stable operational circuit

6. High-precision optical path, minimal scattered light, elimination of higher-order diffraction spectra (equipped with cloud spectrum filter system)

（III). Test Advantages

1. Comparative Testing, Transmittance Testing, Parameter Comparison (Rolling and Locking Modes)

2. Scheduled testing and saving (optical attenuation test verification available)

3. Tunable wavelength for easy search (single band offers more convenience for viewing and analysis)

4. One-click testing and sharing via APPs and mini-programs (WeChat Moments, Weibo, forums, etc.)

5. Test Result Adjustments (coefficients for adjusting test results in different scenarios and environmental changes)

Section II: Optical Path Characteristics (Fiber Spectrometer Structure)

1. Various optical inputs: Cosine Correction Probe, SM905 Fiber Optic (with Cosine Correction)

2. Wavelength Range: 380-1050nm

3. Spectral Resolution: ±0.2nm, Wavelength Resolution:

4. Luminous intensity ±0.3%

5. Scattered Light: <0.1%

6. Luminous probe cosine correction: Error ≤ 5%, Non-linearity ≤ 1%

7. Absolute Fatigue Error: ≤2%

8. Long wave response error: ≤15%

9. Relative Indication Error: ±5%

10. Zero Error: ±1% (FS)

11. Range: Automatic ±1% Error

12. High-speed data collection, integration time: millisecond-level

Focal Length: 42.5mm, Symmetrical Non-Intersecting H-T Optical Path

14. Communication Method: USB Communication

15. Dimensions: 186mm x 80mm x 21.8mm

16. Utilizes advanced microspectrometer technology, offering higher precision than traditional probe testing.

17. Capable of connecting to computer software for testing, and capable of connecting to computer to print test reports.

18. Color LCD display with a user-friendly graphic interface; capable of displaying spectral waveforms and chromatic tolerance ellipses.

19, 5-inch IPS Touchscreen
