Blue Light Hazard Spectrometer
● Blue Light Hazard Irradiance (mW/㎡)
Maximum Radiation Exposure Time (S)
● Blue Light Hazard Rating BER (Mw/Lm)
● Blue-ray Component
● Correlated Color Temperature (Tc) (K), Blackbody Deviation (Duv)
Luminous intensity E (lx)
Candlelight E (Fc)
Radiation Intensity Ee (W/m²)
● Color coordinates (x, y), (u, v), (u', v')
● Relative Spectral Power Distribution P(λ)
● Color Rendering Index Ra, Ri (i=1-15)
● Color Rendering Index (Longitudinal Illustration)
● Color Rendering Index (Illustrative diagram)
● Color Coordinate Chart CIE1976 CIE1960 CIE1931
● Color Difference Diagram SDCM (McAdam ellipse, rectangular box, and CIE u'v' circle)
● Central Wavelength, Peak Wavelength, FWHM Wavelength, Centroid Wavelength, Half-Width
● Brightness to darkness visual ratio
● Color purity, red ratio, green ratio, blue ratio, CIE1931 trichromatic stimulus values X, Y, Z
● Additional functional parameters are customizable
B. Technical Specifications and Indices
● Utilizes advanced microspectrometer technology, offering higher precision than traditional probe testing.
Equipped with computer software, capable of connecting to a computer to print test reports.
● Computer Connection: USB
● Color LCD display with good graphic interface, capable of displaying spectral waveforms and color tolerance ellipse diagrams.
● Spectral Mode: Telecentric Splitter Non-symmetric CT Spectral System
● The sensor utilizes high-precision CCD technology.
● Spectral Bandwidth (FWHM): 2nm
Screen Size: 5.0-inch IPS Full HD Color LCD Touchscreen
● Luminance Test Range: 1-2,000,000 Lux; Resolution: 1 Lux
● Wavelength measurement range: 380nm - 780nm;
● Wavelength Accuracy: ±0.5nm
● Color standard accuracy: ±0.0025, resolution: 0.0001;
● Related color temperature measurement range: 1000-100000K
Resolution: 1K
● Color Rendering Index measurement range: R1-R15
● Total Color Difference Accuracy: ±0.2 within (measurement conditions: under Standard A light source)
● Operating Time: Equipped with a 4000mAh high-capacity lithium battery, it can be used continuously for over 20 hours on a single charge.
● Storage Capacity: Standard with an 8GB high-capacity data storage card, capable of storing over 30,000 records.
Combines spectral, luminance, and chromaticity measurement functions into one.
