Control Box Craftsmanship and Performance Features:
●PU foam gaskets ensure the box reaches IP56 protection level
●Wider cabinet edge frames, load-bearing hinges, and door panel rib reinforcement ensure the high strength of the cabinet system
● Optional 3.0mm galvanized mounting plate and high-strength mounting bracket ensure the reliability of installed components (can be used for wiring outside the box)
● Bottom entry-exit line device ensures flexible and convenient entry-exit lines
● Optional stainless steel transport lifting ring systems ensure convenient and quick transportation
Matte finish with brushed surface (sandblasting available for high-end cabinet interiors)
Material: (Other material models available)
Surface Treatment: Brushed finish, zinc-plated for mounting panels
Protection Class: IP56 (as per GB4205-1993)
Standard Configuration: Door panel, cabinet, sealing strip, grounding kit, mounting plate, door lock
Steel Plate Thickness:
Case: 1.5mm (optional 2.0mm)
Door Panel: 2.0mm
Installation Plate: 2.5mm (optional 3.0mm)
