Control box process features and performance:

●PU foam seals ensure the cabinet achieves an IP56 protection rating

● Wider cabinet side frames, load-bearing hinges, and door panel rib reinforcement ensure the high strength of the cabinet system

● Optional 3.0mm galvanized mounting plate and high-strength mounting bracket ensure reliable installation of components (can be used for wiring outside the box)

● Bottom line entry-exit device ensures flexible and convenient entry and exit lines

● Optional stainless steel transport lifting ring systems ensure convenient and quick transportation

● Surface brushed finish (High-end cabinets can be sandblasted inside)

Material: (Other material models available)

Surface Treatment: Brushed finish; installation panel is galvanized.

Protection Grade: IP56 (as per GB4205-1993)

Standard Configuration: Door panel, cabinet, sealing strip, grounding kit, mounting plate, door lock

Steel Plate Thickness:

Case: 1.5mm (optional 2.0mm)

Door Panel: 2.0mm

Installation Plate: 2.5mm (optional 3.0mm)
