Product Description: Computer Control Cabinet

Computer control cabinets are used for multi-parameter group control of various types of heat treatment equipment, with various technical parameters available for real-time access and storage. Widely applicable to industries such as machinery, metallurgy, power, chemical, food, ceramics, and glass. The control objects can be various electric heating furnaces, such as box furnaces, pit furnaces, ring furnaces, tunnel furnaces, and vacuum furnaces.

Craftsmanship and Performance Features of PC Computer Control Cabinet:

The main body in RAL7035 complements the decorative strip in RAL5018, showcasing the cabinet's high-end quality.

● Monitored area equipped with non-reflective safety glass for secure and reliable operation

● Frames with 90% type profiles ensure flexibility and convenience for internal installation.

● The lower front cabinet door is equipped with a luxurious lever lock, while the maintenance door is fitted with a standard flat lock, showcasing a well-coordinated cabinet design with a focus on user-friendliness.

● The keyboard and mouse system with highly humanized design showcases the cabinet's quality

Material: Cold Rolled Steel Sheet, Aluminum Alloy Profiles

Surface Treatment: Machine cabinet phosphatized base coating, exterior in powder coating, color RAL7035, decorative strips in RAL5018 with two textures, shelves and cabinet in the same color.

Protection Level: IP54 (as per GB4205-1993)

Standard Configuration: cabinet, rear door panel, front upper glass door, front lower steel door, keyboard drawer, sealing strips, shelf panels, door lock, casters (optional)

Steel Plate Thickness:

Trim Strip: Aluminum Alloy

Door panel: 1.5mm; Plywood: 1.5mm

Frame: 1.5mm 90% Shape Aluminum Extrusion
