Control box process features and performance:

●PU foam gaskets ensure the housing achieves an IP56 protection rating

● Wider body frame, load-bearing hinges, and door panel rib reinforcement ensure high strength of the container system

● Optional 3.0mm galvanized mounting plate and high-strength mounting bracket ensure the reliability of the installed components (can be used for wiring outside the box)

● Bottom entry-exit line device ensures flexible and convenient entry and exit lines

Optional stainless steel transport lifting ring systems ensure convenient and quick transportation.

● Surface brushed finish (high-end cabinets can be sandblasted internally)

Material: (Other material models available)

Surface Treatment: Brushed finish, zinc-plated for mounting panels

Protection Level: IP56 (as per GB4205-1993)

Standard Configuration: Door panel, cabinet, sealing strip, grounding kit, mounting plate, door lock

Sheet metal thickness:

Case: 1.5mm (optional 2.0mm)

Door panel: 2.0mm

Installation Plate: 2.5mm (optional 3.0mm)
