Product Description: Computer Control Cabinet

Computer control cabinets are used for multi-parameter group control of various types of heat treatment equipment, with various technical parameters available for real-time access and storage. They are widely applicable in industries such as machinery, metallurgy, electricity, chemicals, food, ceramics, and glass. The control objects can be various electric heating furnaces, such as box furnaces, pit furnaces, ring furnaces, tunnel furnaces, and vacuum furnaces.

Craftsmanship and Performance Features of PC Computer Control Cabinet:

The RAL7035 main body complements the RAL5018 decorative strip, showcasing the cabinet's high-end quality.

● Monitored areas equipped with safety glass with no reflective coating for secure and reliable operation

● Frames with 90% profile materials ensure flexibility and convenience for internal installation.

● The front lower cabinet door is equipped with a luxurious lever lock, while the inspection door uses a standard flat lock, reflecting the cabinet's design with a touch of humanization.

● The keyboard and mouse system with highly humanized design showcases the cabinet's quality.

Material: Cold Rolled Steel Sheet, Aluminum Alloy Profiles

Surface Treatment: Machine cabinet phosphatized primer treatment, exterior with powder coating, color RAL7035; decorative strips in RAL5018 with two textures, shelves and cabinet in the same color.

Protection Level: IP54 (According to GB4205-1993)

Standard Configuration: Cabinet, Rear Door Panel, Front Upper Glass Door, Front Lower Steel Door, Keyboard Drawer, Seal Strip, Shelves, Door Lock, Casters (optional)

Steel Plate Thickness:

Trim Strip: Aluminum Alloy

Door Panel: 1.5mm; Plywood: 1.5mm

Frame: 1.5mm 90% profile
