Product Description
FT-104K-10T, 20T, 30T, 50T, 80T, 100T Four-columnHydraulic Edge Bending MachineFeaturing a four-column, three-plate frame structure with an advanced parent-child cylinder hydraulic circuit. This machine excels in noise, speed, and power consumption compared to standard hydraulic presses, making it a high-efficiency, high-speed, high-force new-generation hydraulic press. Widely applied in the die-casting industry.
Application Scope:
*Hydraulic Edge Bending MachineWidely applied for edge trimming and shaping of various aluminum and magnesium alloy die castings, as well as for precise cutting of plastic products.
Forming of plastic materials such as blanking, stretching, embossing, etc. for sheet materials, as well as pressing for plastics and powder products for various applications.
All types of silicone products, silicone switches, paper products, and plastic materials, in whole or cut to size.
Product Features:
This series of hydraulic flanging machines is powered by a liquid pressure of 3-200MPA, featuring a rapid sub-parent hydraulic circuit, with low noise, low oil temperature, and high efficiency.
2. This hydraulic edge bending machine features a four-column, three-plate open structure. The vertical accuracy of the movable plate is controlled by four precision guide bushes, and it is equipped with an infrared protective light grid.
3. The series hydraulic press is equipped with protective doors on the left, right, and rear sides, facilitating mold installation and maintenance while ensuring operational safety.
4. The control system utilizes PLC programming for operation, allowing for adjustable pressure, stroke, speed, holding time, and closure height to meet specific requirements, ensuring ease of operation.
5. The hydraulic bending machines in this series are equipped with appropriately sized drop holes and automatic feeding devices on the worktable. The system is also fitted with an automatic blowing function, ensuring high efficiency, rapid speed, and cleanliness.
6. Utilizing limit switches, the lifting and pressing points can be freely controlled with precision up to 0.01MM.
7. Utilizing imported low-noise, high-performance high-pressure oil pumps and solenoid valves from Taiwan Group Strategy Motor, with a long service life.
8. Built-in hydraulic system design, compact structure, with processes like baking paint and electroplating, offering an aesthetically pleasing and generous appearance.
9. Comprehensive safety design, operated with both hands, featuring an emergency stop button and up/down point buttons.
Optional accessories include safety protection doors, drop holes, blowing devices, photoelectric safety sensors, force sensors, displacement sensors, etc.
