Features: Compact size, lightweight, high efficiency, high power, low ripple, low energy storage, and high stability and reliability. (Customizable to various power requirements)
Soft Start Function: Continuously adjustable from 1-120 seconds with no overshoot in output.
Digital Communication Function: Offers multiple communication interfaces including RS485, RS232, CAN, TCP/IP, and profibus, enabling data connections with touchscreens, computers, PLCs, and more.
Voltage and Current Signal Feedback: Offers feedback on voltage or current signals ranging from 0-5V, 0-10mA, 0-20mA, and 4-20mA, with sampling of analog voltage and current signals.
Voltage Compensation Function: Offers line voltage drop compensation to reduce voltage drop issues caused by longer output circuit connections.
Voltage/Current Regulation Switch: Automatic switching between VC/CC voltage/current regulation
Reversing Polarity: Can invert the direction of the output positive and negative poles, changing the original positive pole to negative and the original negative pole to positive. Continuous setting from 0-9999S (optional).
Current Voltage Pre-set: Desired voltage and current values can be pre-set when the power is off, and settings can also be adjusted during no-load and operating conditions (standard).
Boot-up Buffer Time: 3-5S
Lock Function: After setting the voltage and current values, press the lock button to lock the parameters in place, preventing accidental changes to the set values.
Power conversion utilizes high-frequency PWM soft-switching IGBT inverter technology, with the control section employing a 16-bit AD conversion and microcontroller control. It features high precision, compact size, and light weight.
High-frequency PWM inverter technology, digital control, 16-bit AD sampling, high precision, high-brightness 4-digit LED display, high performance, high power density, expandable in series and parallel for power/current/voltage
Built-in digital and analog control interfaces (optional), wide range zero voltage and current adjustment, low ripple and low noise, comparable to pure linear power supplies.
Features voltage, current, over-voltage, and over-current preset capabilities, with optional remote voltage drop compensation function.
Application Fields
Voltage regulation and protection for modern high-tech products such as computers and peripheral devices, electronic instruments, communication broadcasting equipment, industrial electronic equipment, and automatic production lines.
Broadly applied to DC power supply in scientific research, colleges and universities, laboratories, industrial and mining enterprises, electroysis, electroplating, charging equipment, etc.
Electronic component testing and aging, battery and capacitor charging equipment, motor testing, precision electroplating, wastewater treatment, LED and LCD screen aging, laboratories, electronic equipment, automatic testing equipment, electronic inspection equipment, production line equipment, communication equipment, and other locations requiring high-precision DC power output.
In applications requiring high-quality DC stable power sources for automatic testing, process control, aging tests, etc.
