Lead wire gabions are mechanically woven from high corrosion-resistant, high-tensile, and ductile low-carbon steel wire, or the aforementioned wire coated with PVC. The box-like structures made from this mesh are called gabion mesh boxes. The diameter of the low-carbon steel wire used, according to ASTM and EN standards, varies with engineering design requirements, generally ranging from 2.0 to 4.0mm. The tensile strength of the gabion mesh wire is not less than 38kg/m², the weight of the metallic coating is usually higher than 245g/m², and the diameter of the edge line of the gabion mesh panels is generally larger than the wire diameter. The length of the double-strand twisted portion must not be less than 50mm to ensure that the metallic and PVC coatings on the twisted wire are not damaged.

(1) Aperture: 60*80mm, 80*100mm, 80*120mm, 100*120mm, 120*150mm, 90*110mm

The length of the double-strand twisting section must not be less than 50mm to ensure that the metallic coating and PVC coating on the twisted steel wire are not damaged.

(2) Wire Diameter: The stone笼 net is divided into three types of wire diameters—mesh wire, edge wire, and binding wire.

The wire mesh range is 2mm to 4mm.

2. Edge wires are generally thicker than mesh wires, 0.5-1.0mm thicker than the mesh wires.

3. Bind wire is generally smaller than mesh wire, with 2.2mm being the most common size.

(3) Wire tensile strength: Not less than 38 kg/m² / 380 N/mm²

(4) Surface Treatment

Electroplated zinc. Zinc coating is 10g/m². Poor corrosion resistance.

2. Hot-dip galvanized. Zinc coating can reach up to 300g/m2. Strong corrosion resistance.

3. Galfan (zinc-aluminum alloy). This is divided into two materials: zinc-5% aluminum-mixed rare earth alloy wire and zinc-10% aluminum-mixed rare earth alloy wire.

4. PVC Coated. The coating thickness typically covers 1.0mm, for instance: after coating, 2.7mm becomes 3.7mm.

Partition: Add a partition every meter along the length of the stone笼 net

(2) Dimensions: Customizable to standard sizes

(3) Diameter Range Corresponding to Hole and Thread Sizes
