Portable Crushers Introduction
The mobile crusher is a product of the new era's demand, characterized by its mobility, ensuring both equipment safety and reliable operation. The mobile crusher improves equipment management and production efficiency to some extent, enhancing users' economic benefits and saving production costs for businesses, making it highly valuable for application and promotion. The new mobile crusher can predict equipment failures, prevent major accidents, reduce downtime, fully utilize equipment potential, ensure stable production line operation, and boost the company's economic benefits.
A mobile crushing station is a multi-stage mining equipment that sorts bulk materials and discharge mining equipment according to certain specifications. It is mainly used for materials that require relocation and processing in metallurgy, chemical industry, building materials, water conservancy, and electricity sectors. Particularly for mobile stone station businesses in road, railway, water supply, and power supply projects, customers can process raw materials and produce finished products with various configurations according to the scale and requirements of different types of materials.
The introduction of mobile crushers eliminates the cumbersome construction of steel frameworks and foundations during crushing, saving a significant amount of time. Mobile crushing stations can be directly selected for a site, transported to the location, and do not require transportation. They directly achieve the desired particle size, particularly suitable for small crushing sites and for the processing and crushing of construction waste. The mobile crushers also greatly reduce investment costs while increasing investment returns.

Performance Features
The mobile crushing machine features well-matched crushing equipment at all levels, smooth material discharge throughout the entire line, reliable operation, and easy handling. Particularly, it boasts excellent mobility, allowing it to extend along with the raw material source or construction site, and can be combined in various ways to meet different material requirements.
Portable Crushers
The mobile crushers are primarily categorized into two types: tire-type and track-type mobile crushing stations. Moreover, they can be customized according to customer requirements, including jaw-type mobile crushing stations, impact-type mobile crushing stations, cone-type mobile crushers, roller-type mobile crushing stations, and single-stage mobile crushers, among others. The assembly process is simple and convenient, effectively achieving integrated machine sets, diverse configurations, wider application scope, and greater flexibility.

Technical Specifications
| Model | RG938HD80 | RG1149HD98 | RG1349HD110 | RG1349HD125 |
| Transport Length (mm) | 12600 | 13500 | 14500 | 15200 |
| Transport Width (mm) | 2600 | 2700 | 2800 | 2900 |
| Transport Height (mm) | 3870 | 4200 | 4450 | 4500 |
| Longer Length (mm) | 12500 | 14000 | 16100 | 16700 |
| Greater Width (mm) | 4100 | 4500 | 5100 | 5100 |
| Higher Height (mm) | 4100 | 4900 | 5000 | 5300 |
| Weight (t) | 39 | 57 | 55 | 65 |
| Tire Specifications | Equipped with dual shafts | Equipped with dual axles | Dual-axle mounted | Belt-driven dual shaft assembly |
| Crushing Machine Model | HD80 | HD98 | HD110 | HD125 |
| Large Feed Size (mm) | 500 | 550 | 660 | 800 |
| Adjustment Range of Discharge Port (mm) | 50-150 | 75-175 | 100-200 | 125-225 |
| Processing Capacity (t/h) | 85-275 | 110-350 | 215-510 | 280-650 |
| Feeding machine model | ZSW380×95 | ZSW420×110 | ZSW490×130 | ZSW490×130 |
| Main Belt Conveyer Model | B800×8.5M | B1000×9.5M | B1000×11M | B1200×11M |
| Side Exit Belt Conveyor Model (Optional) | B500×3M | B650×3.5M | B650×4.5M | B650×4M |
| Generator Set Model (Optional) (kw) | 200 | 250 | 270 | 400 |
| Ironing Model (Optional) | RCYD(C)-8 | RCYD(C)-10 | RCYD(C)-10 | RCYD(C)-12 |
| Model | RG3S1848T71 | RG3S1860T82 | RG3S2160T92 |
| Transport Length (mm) | 13500 | 15600 | 15600 |
| Transport Width (mm) | 2830 | 2830 | 3100 |
| Transport Height (mm) | 4350 | 4350 | 4480 |
| 较长 length (mm) | 14650 | 16300 | 16300 |
| Wide Width (mm) | 3900 | 3900 | 3900 |
| Higher Height (mm) | 5980 | 6400 | 6550 |
| Weight (t) | 31 | 36 | 49 |
| Tire Specifications | Dual-axle mounted | Tri-axis mounted | Three-axis assembled |
| Sand Making Machine | TK7811 | TK8622 | TK9632 |
| Conveyor Belt Machine | B800×2.2M | B800×2.5M | B1000×2.5M |
| Screw conveyor | B800×7M | B800×8M | B1000×8M |
| Vibration Sifter Model | 3YZS1848 | 3YZS1860 | 3YZS2160 |
