Product Overview

The 6955BA/C/E Signal Transceiver is a 3U modular product compliant with the PXIe bus standard. It covers a frequency range of 40MHz to 8GHz/12GHz/26.5GHz, boasts a maximum signal bandwidth of 1GHz, and exhibits single-sideband phase noise of -120dBc/Hz at 20kHz offset (carrier 10GHz, typical value). It features vector signal analysis, vector signal generation, and real-time signal processing and control based on FPGA technology. It can simultaneously receive and transmit microwave vector signals, and offers high-speed, large-capacity storage and processing of signal data. Its exceptional performance makes it widely applicable in fields such as RF semiconductor, communication systems, navigation simulation, 5G testing, IoT testing, and transmitter/receiver equipment testing.

Key Features:

Wide frequency range: 40MHz ~ 8GHz/12GHz/26.5GHz

Wide Signal Bandwidth: Maximum Bandwidth 1GHz

High output power: ≥+17dBm (40MHz~18GHz) (typical value), ≥+10dBm (18GHz~26.5GHz)

8-channel digital IO, programmable IO, and 8-channel trigger channels

Supports system integration with various development environments such as QT, LabWindows, and Microsoft Visual Studio.

Equipped with a high-speed IQ data transfer interface, compatible with data stream disks.
