Product Overview

The 6955AC Signal Transceiver is a 3U, 2-slot modular product compliant with the PXIe bus standard. It integrates vector signal analysis, vector signal generation, and real-time signal processing and control capabilities based on FPGA. It can simultaneously receive and transmit microwave vector signals, and perform high-speed, large-capacity storage and processing of signal data. The module's frequency range is 40MHz to 6.0GHz with a bandwidth of 200MHz. It seeks the optimal configuration of testing efficiency and cost, serving production line testing with a smaller size, higher integration, and faster testing speed. It is widely applicable in fields such as RF semiconductor testing, 5G testing, and IoT testing.

Key Features

Wide Frequency Range: 40MHz ~ 6GHz

Wide Signal Bandwidth: Maximum Bandwidth 200MHz

High output power: up to +15dBm maximum

24-channel digital IO, programmable IO, and 8 trigger channels

Supports system integration with various development environments such as QT, LabWindows, and Microsoft Visual Studio.
