Technical Specifications:

1. Vulcanization Temperature: 145℃

2. Sulfur Pressure: 0.8 Mpa

3. Heating Plate Dimensions: 700×350 (mm)

4. Rated Power: 3.5 kW

Installation Instructions:

① Conduct rubber filling treatment on damaged areas requiring repair (refer to the filling section in the vulcanization process of tape joints, or have the factory service personnel demonstrate during equipment debugging).

② Place the lower shelf beneath the repair area (evenly), on the shelf, position the water pressure plate under the tape, and the lower heating plate (above the repair area).

③ Place a heating plate, an insulating board, and then the upper machine frame below the repaired area, aligning it with the lower machine frame.

④ Install the handle, washer, and nut, then tighten securely.

⑤ Connect the electrical control box to the power source with one set of wires, and connect the heating plate to the electrical control box with another set of wires. Ensure the connections match the labels on the electrical control box.

⑥ Connect the water pump to the water pressure plate using a high-pressure flexible hose, turn on the electrical control box, and fill the water pressure plate with water to the vulcanization pressure.
