Product Description
Heating sources include steam, electric, and electric-steam dual-use options.
◎Operating Temperature: Steam heating 50-140°C, max 150°C; electric heating 50-350°C
The temperature is automatically controlled and recorded by a recording instrument.
The interior walls of the box are fully welded, with rounded transitions at all junctions, ensuring no blind spots.
The machine boasts excellent sealing properties, with a unique guide rail sealing device ensuring the integrity of the machine's seal.
Intake air port equipped with high-efficiency air filters; exhaust moisture port fitted with medium-efficiency air filters.
Double-door oven with mechanical interlocking on both doors.
All components inside the oven can be quickly disassembled and reassembled for easy cleaning.
The control system is equipped with a text display and a touchscreen for selection.
The complete machine meets "GMP" requirements.
Installation Diagram
Specification parameters
Model and Specifications | Each Drying Quantity (kg) | Fan Power (kw) | Steam Consumption (kg/h) | Heating Car (Set) | Baking Sheet (Each) | Width x Depth x Height (mm) | Up and down temperature (°C) |
GMP-O | 35 | 0.45 | 8 | / | 16 | 1130×1100×1750 | ±2 |
GMP-I | 120 | 0.45 | 18 | 2 | 48 | 2300×1200×2000 | ±2 |
GMP-II | 240 | 0.9 | 36 | 4 | 96 | 2300×2200×2000 | ±2 |
GMP-III | 360 | 1.35 | 54 | 6 | 144 | 3430×2200×2000 | ±2 |
GMP-IV | 480 | 1.8 | 72 | 8 | 192 | 4460×2200×2290 | ±2 |
