I. Product Overview

This series of pure water oxygen generators utilizes Solid Polymer Electrolyte (SPE) oxygen generation technology, using pure water as the electrolyte and producing high-purity oxygen through electrolysis with titanium metal electrodes. The oxygen is then separated from water, dried, and purified before being output, featuring stable pressure (fluctuations < 0.001 MPa), on-demand production, and zero addition of alkaline solution. It is suitable for laboratory, medical, and industrial applications.

III. Instrument Features

1. Smart Control System

One-touch operation: Simply press the power switch to start gas production, supports continuous or intermittent operation.

Precise Monitoring: A high-definition LED digital display shows flow rate (±1ml accuracy) and pressure values in real-time, with data being clear and easy to read.

Pressure-adaptive: When the pressure reaches the preset value (e.g., 0.4 MPa), the system automatically adjusts the gas production volume to ensure the output pressure fluctuation ≤ 0.001 MPa.

2. Low-maintenance design

Simplified Maintenance: Simply replenish with pure water or double-distilled water on a regular basis.

3. Safety Protection

Anti-Backflow Technology: Equipped with an anti-backflow device, eliminating the risk of liquid backflow.

Multiple Protection: Over-pressure and low-liquid automatic shutdown to ensure equipment and operation safety.

4 High-Efficiency Compact Structure

High Conversion Efficiency: Electrolytic cell efficiency ≥95%, maximum gas production up to 200ml/min, meeting high load requirements.
