I. Product Overview

This series of pure water oxygen generators utilizes Solid Polymer Electrolyte (SPE) oxygen generation technology, using pure water as the electrolyte and producing high-purity oxygen through electrolysis with titanium metal electrodes. The oxygen is then separated from water, dried, and purified before being output, featuring stable pressure (fluctuations < 0.001 MPa), on-demand production, and zero addition of alkaline solution. It is suitable for laboratory, medical, and industrial applications.

III. Instrument Features

1. Smart Control System

One-touch operation: Simply press the power switch to start gas production, supporting continuous or intermittent operation.

Accurate Monitoring: Highlighted LED digital screens display flow (±1ml accuracy) and pressure values in real time, with data being clear and prominent.

Pressure Adaptive: The system automatically adjusts the gas production volume when the pressure reaches the preset value (e.g., 0.4 MPa), ensuring the output pressure fluctuation is ≤0.001 MPa.

2. Low-maintenance design

Simplified Maintenance: Simply replenish with pure water or distilled water periodically.

3. Safety Protection

Anti-backflow Technology: Equipped with an internal anti-backflow device, eliminating the risk of liquid backflow.

Multiple Protection: Over-voltage and low-liquid auto shutdown to ensure equipment and operation safety.

4 Efficient and Compact Structure

High conversion efficiency: Electrolytic cell efficiency ≥ 95%, maximum gas output of 3,000 ml/min, meeting high load requirements.
