Mining Light Duty Rubber Sheathed Cable MYQ-4×1.5

1. The insulation resistance between the main cores of MYQ cable and between the main cores and the ground wire, when converted to +20°C, is not less than 160 MΩ·km.

2. MYQ Cable Product Standard: MT818.9-1999.

3. The MYQ type cable is composed of 2 to 12 main cores, and after cabling, it is sheathed with a black chlorinated polyethylene rubber jacket or a black chloroprene rubber jacket externally. 4. MYQ cable conducting cores: made of soft copper wire, which meets the performance standards of GB/T3956-1997.

5. MYQ Cable Insulation: Uses XJ-00A type rubber as specified in GB7594.2-1987.

6. MYQ Cable Core Identification: Up to four cores use insulated color coding for identification, while cores above four use printed numbering for identification.

7. MYQ Cable Twisting: Twisted in a right-hand lay.

8. MYQ Cable Sheath: Made of XH-01A rubber as specified in GB7594.7-1987.

9. The standard UYQ type finished cables of MYQ cables are non-flammable, and the flame-retardant UYQ type finished cables meet the requirements of MT386-1995.

10. MYQ Cable Labeling: The cable surface is printed with the model, voltage, specifications, and manufacturer's name.

Mining Industry Light Rubber Sheathed Cable MYQ-4×1.5
