500kw Silent Diesel Generator Dimensions and WeightDiesel generator sets are small-scale power generation equipment, referring to power mechanisms that use diesel fuel or similar as the fuel and diesel engines as the prime mover to generate electricity. The complete set usually consists of components such as diesel engines, generators, control boxes, fuel tanks, starting and control batteries, protective devices, and emergency cabinets. They can be mounted on a foundation for fixed use or installed on trailers for mobility. Diesel generator sets are non-continuous operation power generation equipment; if they operate continuously for more than 12 hours, their output power will be approximately 90% of the rated power. Although diesel generator sets have lower power, due to their compact size, flexibility, light weight, and complete accessories, they are easy to operate and maintain. Therefore, they are widely used in mines, railways, construction sites, road traffic maintenance, and in factories and enterprises as backup or temporary power sources.

TO520000ETDetailed specifications

I. Technical Specifications

Rated Output：  500KVA

BackupPower：  520KVA

Rated Frequency： 50Hz

Rated Voltage： 400V

Rated Speed： 1500

Generator Type: Style

Startup Method:  Electric start

Please provide the Chinese content you would like translated into American English.    Number: Three-phase

Power Factor： COSΦ = 0.8 (lagging)

Adjustment Method:  AVR (Automatic Voltage Regulator)

Steady Voltage Regulation:(%):≤±0.5

Voltage Fluctuations：  (%):≤±0.5

Load Surge Voltage%： ≤±3

Steady-state Frequency Adjustment%： ≤±2

Engine Technical Specifications:

Power Model:  TO52000ET

Cylinder arrangement: Inline  Four-stroke Dry Cylinder Liner

Cylinder Quantity: 12-cylinder

Cooling Method:  Forced closed-loop water cooling system

Supply Method:  Direct喷射燃烧式

Speed Control Method:  Mechanical Speed Regulator

Noise-suppression device:  Industrial equipment

Inlet method:  Turbocharger

Oil Type:  SAE 10W-30 (or CD)

Fuel Model:  0# -10#Diesel

Diesel Fuel Tank  350L

Engine oil consumption:224g/kw•h

Motor Technical Specifications:

Rated Power:  500KW

Wiring Method:  Three-phase, four-wireY-connection

Protection Level:  IP22

Insulation Grade:  H Level

Motor Type: Brushless Motor

Other Configurations:

Dimensions of the unitL×B×H）：4850*1900*2400mm

Office Hours:8-10H

Engineered Weightkg）：5200/5300

500kw Silent Diesel Generator Dimensions and WeightPrice is the index of the exchange ratio of goods, or in other words, the monetary representation of *. Price is the transformed form of the exchange of goods in the process of circulation. In the process of economics and business, price is a * figure established for goods, services, and assets in terms of money. In microeconomics, price is one of the important variables in the process of reallocating resources between demand and suppliers.
Diesel-powered with a compact structure, small size, and light weight, up to 30% lighter than comparable diesel generators. *General generators have messy energy-consuming devices such as excitation windings, excitation machines, and AVR voltage regulators. Power and power factor are 20% higher than general generators. *High overload capacity, capable of powering UPS power sources, air conditioners, motors, and other rational loads equivalent to its capacity. High overcurrent capacity up to 100%. Good voltage stability under sudden load changes, voltage fluctuation rate not exceeding 0.5%, waveform distortion rate not exceeding 2%, suitable for precision instruments and surface applications. Continuous full-load operation of the motor does not exceed 50°C, resolving the "heating" issue during long-term full-load operation of generators.
