400kw Silent Diesel Generator, Oilfield Backup  Low-power diesel generator sets are widely used due to their compact size, flexibility, light weight, complete accessories, ease of operation and maintenance. They serve as backup or temporary power sources in mining, railways, construction sites, road maintenance, and factories, enterprises, etc. They have solved the difficult problems in the control field of generator sets. This is an automated system composed of *controllers, which are tailor-made for generator sets, integrating multiple functions into one, eliminating complex peripheral circuits, and making the automated control system simpler. These *controllers mostly use microprocessors and control technologies, significantly improving **reliability and environmental adaptability compared to PLCs. Additionally, many parameters can be set according to actual conditions, making them highly flexible to use.

TO420000ETDetailed specifications

I. Technical Specifications

Rated Output：  400KVA

BackupPower：  420KVA

Rated Frequency： 50Hz

Rated Voltage： 400V

Rated Speed： 1500

Generator Type: Style

Startup Method:  Electric Start

Please provide the Chinese content to be translated.    Number: Three-phase

Power Factor： COSΦ = 0.8 (lagging)

Adjustment Method:  AVR (Automatic Voltage Regulator)

Steady-state voltage regulation:(%):≤±0.5

Voltage Fluctuations：  (%):≤±0.5

Load surge voltage%： ≤±3

Stable Frequency Adjustment%： ≤±2

Engine Technical Specifications:

Power Model:  TO42000ET

Cylinder arrangement: Inline  Four-stroke Dry Cylinder Liner

Cylinder Quantity:  6-cylinder

Cooling Method:  Forced-closed water circulation cooling system

Fuel supply method:  Direct-injection combustion

Speed regulation method:  Mechanical speed control

Silencer unit:  Industrial Equipment

Inlet method:  Turbocharger

Engine Oil Model:  SAE 10W-30 (or CD)

Fuel Model:  0# -10#Diesel

Diesel Fuel Tank:  300L

Engine Oil Consumption:224g/kw•h

Motor Technical Specifications:

Rated Power:  400KW

Wiring Method:  Three-phase four-wireY-connection

Ingress Protection Rating:  IP22

Insulation Grade:  H Level

Motor Type: Brushless Motor

Other Configurations:

Overall dimensions of the unitL×B×H）：4300*1500*2300mm

Office Hours:8-10H

Engineered Weightkg）：3600/3800

400kw Diesel Generator - Oilfield Backup   Controller uses a microprocessor, featuring program control operation alarm, strong signal processing capability, multiple monitoring functions, fast response speed, accurate control, high precision, easy expansion, manual/automatic operation, various signal instruments, LED indicator lights for important information, and LCD displays. There's compensation for success, but shame for failure. Promotion philosophy: Create achievements, cultivate talents, and be promoted. Management philosophy: The warmth of friendship, the impersonality of management, and the ruthless system. Responsibility: Responsible to oneself, family, company, and society. Morality creates talents – talents create Shanghai Sun Gong Power Generation Equipment Factory, meticulously crafted by a team of over 30 young engineers in the industry, dedicated to the research and development of general-purpose gas, diesel, and gas engines and their terminal products.
