Chain Conveyors include the driving box (driven box),8Sprockets, motor reducers, conveyor chains with sprocket wheels, and material conveying pipelines. Both sides of the drive box (driven box) are equipped with spigots, which are connected to the drive box (driven box).8The sprocket chain is mounted inside the drive housing (driven housing), with the conveying tube shaped as a bend and connected by flanges. The ends of the conveying tube are connected to the branches on both sides of the drive housing (driven housing) respectively. The conveying chain passes through the bore of the conveying tube and branches to transmit power to the drive sprocket. The cross-section of the conveying tube is circular. The conveying chain consists of horizontal and vertical links, all shaped like anchor chains, with disks fixedly mounted on the vertical links, which are also circular. The conveyor has a simple and rational structure and can be used in narrow and irregular spaces, widely applied in material conveying. Depending on the user's on-site space requirements, the tube chain conveyor can also be used independently for horizontal, inclined, or vertical lifting, and can achieve conveying applications with multiple feeding or discharge points. A directional sprocket can also be set at the bend in the pipe for chain direction reversal.

Advantages:
1The tube chain conveyor features a simple and compact structure, which can be horizontally, vertically, curved, or arranged in three dimensions.
2According to the on-site usage of the users, multiple inlets and outlets can be implemented, achieving a single conveyor chain with multiple points for feeding and discharging.
3The conveying material remains sealed between the import and export flanges throughout transportation, ensuring no dust leakage into the environment.
4Exporting does not require dust collectors; simple exhaust ventilation is sufficient, meeting modern enterprises' environmental protection requirements.
4During transportation, nitrogen can be infused for protection, meeting the requirements for conveying flammable and explosive powdered materials.
5The raw materials are smoothly transported forward between the two disks along the pipe, with minimal friction. So, material breakage is minimal, and the slow curve conveyance results in very little material becoming broken.
6Baiken Chain Conveyors are all equipped with specially customized conveyor discs. ,Extremely low friction coefficient, high wear resistance, and stable conveying.
7Baiken's chain conveyor systems utilize self-developed calculation programs, ensuring necessary static friction and tension on different parts such as the conveying pipeline and elbows, providing high data for designing low-noise and low-wear chain conveyors.

Conveying Features:
1The tube chain conveyor features a simple and compact structure, allowing for horizontal, vertical, curved, or 3D layouts.
2The pipeline can be fully enclosed for transportation, with no dust leakage, ensuring environmental protection.
3During material conveying, under the same conveying capacity, the pipe chain energy consumption can be limitedly reduced to minimize operating costs.
4Up to 50 meters horizontal conveying distance60Rice, enhance height46Meters (usually promoted by domestic manufacturers as)40Rice, but not necessarily, but Baiken46Pipe chain at 1 meter height in IndiaPTAProject successfully implemented). Capabilities up to60 m?/h。
5Low maintenance, low maintenance cost, and long service life.
6Minimal friction, maximum noise reduction.
7All materials can be fully conveyed without any residue remaining in the conveying pipeline.
8Operational speed is slow to ensure the integrity of materials to a certain extent.
9Incorporates explosion-proof and airtight design capabilities.
10Can be loaded with materials and started.
11Other advantages see chain conveyor.
